Crawler Hydraulic Rotary Borehole Rock Drilling Rig for Sale

Henan Jeao Heavy Industry Machinery Co., Ltd.
  • Certification：ISO 9001:2000, ISO 9001:2008
  • Condition：New
  • Drill Hole Diameter：90-130mm
  • Drill Hole Depth：25m
  • Bit Type：Diamond Bit
  • Drilling Way：Impactor

Base Info

  • Model NO.：HC726A1
  • Rock Hardness：F=6-20
  • Air Consumption(M3/Min)：7-16
  • Working Pressure(MPa)：0.7-1.5
  • Main Motor Power(Kw)：40kw
  • Traveling Speed(Km/H)：2.5
  • Drill Rod：76*3000mm
  • Drill Bit：90mm
  • Hammer：930
  • Weight(Kg)：4200
  • Dimension(mm)：5260*2045*1950mm
  • Transport Package：Nude Packing
  • Specification：ISO
  • Trademark：HONGWUHUAN
  • Origin：Zhejiang
  • Production Capacity：300sets,Month

Description

Diesel Engine

Model

6BTA5.9-C180 (CUMMINS)

Type

Air cool

Cylinder

6pcs

Working power

132kw

Rated rotation speed

2200rpm

No-load rotation speed

1400rpm

Lube oil capacity

18L

Fuel tank capacity

210L

Coolant capacity

45L

Battery

6-QW-135MF*2
