Superior Stability 205c10 Rotary Drilling Rig
Newindu Construction Engineering (Shanghai) Co., Ltd.- After-sales Service：Online Service
- Warranty：One Warranty
- Certification：CE
- Condition：New
- Drill Hole Diameter：>300mm
- Drill Hole Depth：>150m
Base Info
- Model NO.：205C10
- Bit Type：Diamond Bit
- Drilling Way：Compound
- Type：Crawler
- Rated Power：125kw
- Dimension：3980*3130*6500mm
- Max Thrust-Pull Force：6600kn
- Transport Package：LCL, 20gp
- Specification：25000kg
- Trademark：CHIAN TOP BRAND
- Origin：China
- HS Code：8427209000
- Production Capacity：100
Description
Basic Info.
Model NO. 205C10 Bit Type Diamond Bit Drilling Way Compound Type Crawler Rated Power 125kw Dimension 3980*3130*6500mm Max Thrust-Pull Force 6600kn Transport Package LCL, 20gp Specification 25000kg Trademark CHIAN TOP BRAND Origin China HS Code 8427209000 Production Capacity 100Product Description
Superior Stability 205C10 Rotary Drilling RigProducts Description
1.Patented technology of power head floating and vise floating can greatly protect the drill pipe thread to increase the service life of the drill pipe.
2.High/low speed push-pull and rotation system in which the variable piston motor achieves the high/low push-pull speed of power head improves the ability to adapt to various working conditions and improves the construction efficiency of the drilling rig.
3.The configuration is flexible and diverse. The whole machine can be equipped with automatic (semi-automatic) pipe loader, double automatic anchoring device, mud antifreeze, mud cleaning device, etc. It can also be equipped with more environmentally friendly and energy-saving engine.
Product Paramenters
| 205C10 | Unit | Parameters |
| Max.Drilling Dia. | mm | 1500 |
| Max.Drilling Depth | m | 55 |
| largest torque | kN.m | 150 |
| Speed of rotary drive totation | rpm | 7-14 |
| Max.push | kN | 150 |
| Max.pull | kN | 160 |
| Crowd stroke | mm | 4250 |
| Mast sideward | . | (+/-)5 |
| Mast forward | . | 5 |
| Main winch pull(1st layer) | kN | 160 |
| Main winch wire rope dia. | mm | 28 |
| Max.main winch line speed | m/min | 70 |
| Aux.winch pull(1st layer) | kN | 60 |
| Aux.winch wire rope dia. | mm | 14 |
| Engine | CC-6BG1TRP |
| Engine power | KW(HP) 125 (168) @2100rpm |
| Style | 4-storke,water-colled,overhead value type and electronic injection |
| Intake form | Turbocharged, inter cooling |
| Fuel | Diesel oil |
| Emission regulation | EU stage II/EPA Tier 2 |
| No of cylinder-bore*stroke | 6-105mm X 125mm |
| Displacement | 6.494 |
| Compression ration | 17.5:1 |
| Rated power | 125KW @ 2100rpm |
| 168HP @ 2100rpm | |
| Max. output torque | 637.9N.m @ 1800rpm |
| 864lbf.ft @ 1800rpm |
