Mini Portable Mining Hydraulic Used Water Well Borehole Core Drilling Rig Machine
Henan Yugong Machinery Co., Ltd.- After-sales Service:Lifetime Warranty
- Warranty:1year
- Certification:CE, ISO 9001:2000, ISO 9001:2008
- Condition:New
- Motor:AC Motor
- Drill Hole Diameter:250-300mm
Base Info
- Model NO.:YGX130-200
- Drill Hole Depth:150-200m
- Bit Type:Diamond Bit
- Drilling Way:Rotary
- Drilling Depth:130-200m
- Open Hole Dia.:220-325mm
- End Hole Dia.:75mm
- Drill Rod Dia.:42-60mm
- Drill Angle:90°-75°
- Matching Power:13.2, 14.7
- Weight:600-970kg
- Spindle Speed:142,285,570(R,Min)
- Mud Pump Flow:95-145(L,Min)
- Mud Pump Max.Pressure:1.2-2MPa
- Custom:Support
- Warranty Period:Two Years
- Item:Water Well Drilling Rig
- Application:Core Sample Geological Exploration
- Advantage:Cheap Fast Drilling Speed
- Transport Package:Wooden Case
- Specification:2400*800*1400mm
- Trademark:YUGONG
- Origin:China
- HS Code:8430411900
- Production Capacity:100sets,Month
Description
Mud pumpModel BW95 BW95 BW145 Flow 95L/min 95L/min 145L/min Maximum pressure 1.2Mpa 1.2Mpa 2Mpa Reciprocating frequency 93times/min 93times/min 93times/min Suction pipe diameter Φ51mm*4.5m Φ51mm*4.5m Φ51mm*4.5m
Our services
1.Any inquiries will be replied within 12 hours.
2.Professional manufacturer, Welcome to visit our factory at any time.
3.High quality, fashion designs, reasonable & competitive price and fast lead time.
4. Protection of your sales area, ideas of design and all your private information.
5.Shipping:We have strong cooperation with DHL, TNT, UPS, FedEx, EMS, China air post.You also can choose your own shipping forwarder.
Company Information
packaging &shipping
Our services
1.Any inquiries will be replied within 12 hours.
2.Professional manufacturer, Welcome to visit our factory at any time.
3.High quality, fashion designs, reasonable & competitive price and fast lead time.
4. Protection of your sales area, ideas of design and all your private information.
5.Shipping:We have strong cooperation with DHL, TNT, UPS, FedEx, EMS, China air post.You also can choose your own shipping forwarder.
Company Information
packaging &shipping
1. Packaging: 1)Wrapped by proctective film;
2)Packed by standard import & export wooden cases or carton boxes.
2. Shipping: By logistics; by automobile; by train; by shipping; by air etc.
If you need more details and lastest price,feel free to contact me:
Conact:Jane Zhao
Add: F 26/27 Block B, Jingsha Plaza 8# Jingguang South Road, Zhengzhou, China
