Fbu Flush by Unit Xj150/250/350/450/550 Flushing Well Workover Rig

Puyang Chensheng Petroleum Technology Co., Ltd.
  • After-sales Service：1year
  • Warranty：1year
  • Certification：ISO 9001:2008
  • Condition：New
  • Motor：DC Motor
  • Drill Hole Diameter：250-300mm

Base Info

  • Model NO.：XJ150,250,350,450,550
  • Drill Hole Depth：>300m
  • Bit Type：Cone Bit
  • Drilling Way：Rotary
  • Drilling Depth：2000m
  • Wireline Diameter：19
  • Workover Depth：3200
  • Transport Package：Bulk
  • Specification：steel
  • Origin：Puyang Henan China
  • HS Code：84304129
  • Production Capacity：100

Description

                                      1"(26)                                                                               35MPa12≤900013

Adjustable height range of platform:     1.2m-2.7m It consists of  special Workover rig chassis, power transmission system, plunger pump, angle gearbox, drawworks with brake system, double type mast, traveling system with weight indicator, water tank, pneumatic and electrical systems for drilling control etc.This product is applied to workover job and sand flushing job of oil and water well etc.
Power system: high speed diesel engine, hydraulic mechanical transmission; diesel engine + hydraulic mechanical transmission; equipped with CAT diesel engine and it matched with Allison  hydraulic transmission box, with excellent performance.

Air-hydraulic control system: hydraulic system is used for leveling hoisting hydraulic jack, mast raising, mast support cylinder and the working of hydraulic tong. Air system is used for the controlling winch clutch, emergency brake cylinder, the throttle of triplex plunger pump. It realizes combination and separation of the clutch and winch brakes in emergency.
