Wheel Mounted Portable DTH Air Water Well Drilling Rig
Ji Ning Hengwang Mining Machinery Co., Ltd.- Certification：CE, ISO 9001:2000
- Condition：New
- Drill Hole Diameter：150-200mm
- Drill Hole Depth：100-150m
- Bit Type：Diamond Bit
- Drilling Way：Rotary
Base Info
- Type：Four-Wheel Trailer
- Dia of The Hole：80-100mm
- Depth of The Hole：≥20m
- Rotation Speed：0-84rmp
- Working Pressure：0.5-0.7MPa
- Specification of Drill Rod：60*1000mm
- Air Consumption：≥7m3,Min
- Lifting Power：9600n
- Weight：500kg
- Motor Power：4kw
- Capacity (M³/Min)：9
- Transport Package：Wooden Case
- Specification：CE, SGS
- Trademark：HW
- Origin：Shangdong China
- HS Code：8430390000
- Production Capacity：50000set,Year
Description
EngineDiesel Manufacturer Cummins / Yuchai Model No. WD415.23-230 Cooling System Water-cooled Bore × Stroke × Cylinder 130×163×6 Rated Power 140kw Voltage(V) 24 Unloaded Speed / Maximum Loaded Speed 1300 / 1800RPM
