Hfp1000 96/75.7mm Rock Engineering Drill Hydraulic Portable Core Borehole Drilling Rig Machine
Zhengzhou Hanfa Prospecting Machinery Co., Ltd.- After-sales Service：Online Support,Field Maintenance
- Warranty：1 Year
- Certification：CE, RoHS, ISO 9001:2000, ISO 9001:2008
- Condition：New
- Motor：132kw
- Drill Hole Diameter：96,75.7mm
Base Info
- Model NO.：Hfp1000
- Drill Hole Depth：400,1000m
- Bit Type：Diamond Bit
- Drilling Way：Rotary
- Drilling Depth：400,1000m
- Hole Diameter：96,75.7mm
- Core Diameter：71,56mm
- Engine Power：132kw
- Rotary Torque：1000n.M
- Rotation Speed：1300rpm
- Feed Travel：1.83m
- Winch Average Speed：150m,Min
- Winch Pulling Force：750kg
- Winch Wire Rope Diameter：5mm
- Transport Package：Standard Export Packing or as You Needs
- Specification：2.5m*2.5m*3.8m
- Trademark：HF
- Origin：Zhengzhou City, China
- HS Code：843041
- Production Capacity：50sets,Month
Description
Product Parameters Model HFP1000 Drill rod model HTW/NTW/BTW Drill rod length 1.5m Drilling capacity 400/1000m Drilling diameter 96/75.7mm Core diameter 71/56mm Hoist Average speed 150m/min Lifting power 750kg Wire rope diameter 6mm Rope capacity 1300m Hydraulic system Rig power KUBOTA V1505-T Turbocharged diesel engine 4x33kw/3000rpm = 132kw Maximum pressure 21MPa Maximum flow 280L/min Mud pump Maximum flow 120L/min Maximum pressure 7MPa Top drive power head Drilling angle 45°- 90°/0°- 90° Optional bracket Maximum torque 1200N·M Maximum speed 1300rpm Give progress 1.83m Lifting force/feeding force 60KN/30KN (Double cylinder power) Holder Clamping capacity 114/HTW/NTW/BTW Machine area 4mx4m×5m Number of modules 13PCS Heaviest module 180kg Weight 1680kg
