Down-The Hole Open-Pit Mines Hydraulic Drill Rigs with DTH Hammer
Ji Ning Hengwang Mining Machinery Co., Ltd.- After-sales Service：Yes
- Warranty：Yes
- Certification：CE, ISO 9001:2000, ISO 9001:2008
- Condition：New
- Motor：Yuchai
- Drill Hole Diameter：90-130mm
Base Info
- Model NO.：HW420
- Bit Type：Diamond Bit
- Drilling Way：Rotary
- Rated Power：58kw
- Hole Depth：30m
- Pull up Force：25 Kn
- Feed Force：15 Kn
- Rotation Torque (Max.)：2200 N.M
- Drill Pile Sizes：76 X 3,000 mm
- Hole Dia：90-130 mm
- Tramming Speed (Max.)：2.5 Km,H
- Gradient：25°
- Total Weight：4000kg
- Transport Package：Standard Packaging
- Specification：5700 X 2130 X 2200 mm
- Trademark：Hengwang
- Origin：Shangdong
- Production Capacity：100PCS ,Month
Description
Transportation Dimensions
5700 X 2130 X 2200 mm
