Hydraulic Drilling Separated DTH Surface Drilling Rig Machine Made in China
Ji Ning Hengwang Mining Machinery Co., Ltd.- After-sales Service：Yes
- Warranty：Yes
- Certification：CE, ISO 9001:2000
- Condition：New
- Motor：Yuchai
- Drill Hole Diameter：90-127 mm
Base Info
- Model NO.：HW416
- Drill Hole Depth：20m
- Bit Type：Diamond Bit
- Drilling Way：Impactor
- Model：Hw416
- Power：Yuchai Yc4dk80
- Rated Power：58kw
- Drill Pipe Sizes：60*3000 mm
- Hole Range：90-127 mm
- Rotation Torque (Max.)：1,950 N.M
- Rotation Speed：70-150 Rpm
- Feed Force：15 Kn
- Pull up Force：25 Kn
- Feed Type：Chain
- Tramming Speed (Max.)：2.5 Km,H
- Gradient：25°
- Total Weight：3,250kg
- Transportation Dimensions：4,900X2,000X2,200 mm
- Specification：58KW
- Trademark：Hengwang
- Origin：Shangdong China
- HS Code：8429510000
- Production Capacity：500set,Year
Description
Transportation Dimensions4,900X2,000X2,200 mm
