Specially Design Surface DTH Drill Mine Blasting Rig for Open Use

Zhengzhou Hanfa Prospecting Machinery Co., Ltd.
  • After-sales Service：Online Support,Field Maintenance
  • Warranty：1 Year
  • Certification：CE, RoHS, ISO 9001:2000, ISO 9001:2008
  • Condition：New
  • Drill Hole Diameter：Ф114-219mm
  • Drill Hole Depth：40m

Base Info

  • Model NO.：Hf054
  • Bit Type：Diamond Bit
  • Drilling Way：Rotary
  • Type：Crawler
  • Drilling Diameter：114-219mm
  • Drilling Depth：40m
  • Working Air Pressure：1.2-2.4MPa
  • Air Consumption：11 -25mm³,Min
  • The Biggest Pipe-Rod Changing Length：3m
  • Propulsion Power：6000kgf
  • Moving Speed：2km,H
  • Gradeability：24°
  • Power：30-70kw
  • Weight：6200kg
  • Transport Package：Standard Export Packing
  • Specification：CE, ISO
  • Trademark：HANFA
  • Origin：Zhengzhou City, China
  • HS Code：843041
  • Production Capacity：30sets,Month

Description

Overview Product Description

Product Parameters



Drilling diameter



follow-pipe :Ф114-Ф219mm

Down-hole :Ф105-Ф200mm



Drilling depth

follow-pipe :40m

Down-hole :200m

Working air pressure

1.2-2.4Mpa

Air consumption

11 -25mm³/min

The biggest pipe-rod changing length

3m

Propulsion power

6000kgf

Moving speed

2km/h

Gradeability

24°



Power

internal combustion 70kw

Electric           30kw

Outer size(L*W*H)

(transportation state)6900*2200*2200

Weight

6200kg

Dust removol

Wet type(optional)

Company Profile

Specially Design Surface DTH Drill Mine Blasting Rig for Open UseSpecially Design Surface DTH Drill Mine Blasting Rig for Open UseSpecially Design Surface DTH Drill Mine Blasting Rig for Open UseFAQ

1. Are you a trading company or a manufacturer?
We are a professional manufacturer. Our factory mainly produces water well drilling rigs, core drilling rigs, down-the-hole drilling rigs, pile drivers, etc. The products have been exported to hundreds of countries around the world and enjoy a high reputation all over the world.

2. How is the quality of your machine?
Our products pass strict quality inspections before they leave the factory to ensure that they are qualified before they are shipped.

3. How to inspect the goods?
1) Support customers to come to the factory for on-site inspection.
2) Support customers to designate third-party companies to inspect goods.
3) Support video inspection.

4. Do you have after-sales service?
Yes, we have a dedicated service team that will provide you with professional technical guidance. If you need, we can send our engineers to your workplace and provide training for your employees.

5. How about quality assurance?
We provide a one-year quality guarantee for the main machine of the machine.

6. How long is your delivery cycle?
1) In the case of stock, we can deliver the machine within 7 days.
2) Under standard production, we can deliver the machine within 15-20 days.
3) In the case of customization, we can deliver the machine within 20-25 days.
