Portable Integrated DTH Surface Borehole Drilling Rig
Ji Ning Hengwang Mining Machinery Co., Ltd.- After-sales Service：Yes
- Warranty：Yes
- Certification：CE, ISO 9001:2008
- Condition：New
- Motor：AC Motor
- Drill Hole Diameter：100-150mm
Base Info
- Model NO.：40m
- Drill Hole Depth：<100m
- Bit Type：Hammer Bit
- Drilling Way：Impactor
- Hole Depth：40m
- Drill Pile Sizes：60mmx3000mm
- Hole Dia：80-115mm
- Rotation Torque (Max.)：1650n.M
- Working Pressure：14.5 Bar
- F.a.D：12m3,Min
- Gradient：30 Degree
- Total Weight：6800 Kg
- Transportation Dimensions：6000X2800X2750 mm
- Power：Yuchai Yc6j220 162 Kw
- DTH Hammer：3.5"
- Dry Dust Collector：Option
- Rotation Speed：0-110 Rpm
- Tramming Speed (Max.)：2,3 Km,H Dual Speed
- Dual Speed Walking Motor：Standard
- Transport Package：FCL
- Specification：5300*1750*2720mm
- Trademark：Hengwang
- Origin：China
- Production Capacity：1000sets,Year
Description
Main technical specifications
Power
Yuchai YC6J220 162 kW
Hole Depth
40m
Drill Pile Sizes
60 mmX3000 mm
Hole Dia
80-115mm
DTH Hammer
3.5"
Rotation Torque (Max.)
1650N.m
Rotation Speed
0-110 rpm
Working Pressure
14.5 bar
F.A.D
12 m3/min
Tramming Speed (Max.)
2/3 km/h Dual Speed
Gradient
30°
Track Frame Oscilation
±10°
Total Weight
6,800 kg
Transportation Dimensions
6,000X2,800X2,750 mm
Dry Dust Collector
Standard
Dual Speed Walking Motor
Standard
FAQ
Q1. What is your terms of payment?
Ans.: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance.
Q2. What is your terms of delivery?
Ans.: EXW, FOB, CFR, CIF.
Q3. How about your delivery time?
Ans.: Generally, it will take 7 -10 working days after receiving your advance payment.
The specific delivery time depends on the items and the quantity of your order.
Q4. What is the warranty of our machine?
Ans.:Our main machine enjoys a 1 year warranty, during this time all accessories broken can be changed for a new one. And we provide videos for machine install and operation.
Q5. What is your terms of packing?
Ans.: Generally, we use standard exported wooden case for LCL goods, and fixed well for FCL goods.
Q6. Do you test all your goods before delivery?
Ans.: Yes, we have 100% test before delivery.And we will attach our inspect report for every machine.
Q7.Do you Preferred provide wear parts for transacted clients?
Ans.: Yes, we have records for your clients, and will prefer providing accessories to clients.
Q8: How do you make our business long-term and good relationship?
Ans.: 1. We keep good quality and competitive price to ensure our customers benefits;
2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
