Hydraulic Underground Tunnel Drilling Rig DTH Hammer Driller
Ji Ning Hengwang Mining Machinery Co., Ltd.- After-sales Service：Yes
- Warranty：Yes
- Certification：CE
- Condition：New
- Drill Hole Diameter：<100mm
- Drill Hole Depth：150-200m
Base Info
- Model NO.：HW412
- Bit Type：Diamond Bit
- Drilling Way：Mobile Gyrator
- Transport Package：Standard Packing
- Specification：2300*1100*1600 mm
- Trademark：HW
- Origin：China
- Production Capacity：1000PCS,Month
Description
Diesel Engine Specifications
Rig Model
Power
Rated Power
HW412A
Xichai
4DW91-50GBG3U
36.8kW
HW412A-1
YC4DK80
58kW Dust collection system as standard equipment
General Specifications
Drill Pipe Sizes
60*2000 mm
Hole range
90-110 mm
Rotation torque (Max.)
1,650 N.m
Rotation Speed
70-150 rpm
Feed Force
15 kN
Pull Up Force
25 kN
Feed Type
Chain / cylinder
Tramming Speed (Max.)
2.5 km/h
Gradient
25°
Total Weight
3,350Kg/ 3,760 kg
Transportation Dimensions
4900X2000X2200 mm
