• Model NO.：BOP rubber
• Specification：As per Model
• Trademark：Beyond
• Origin：China

Basic Info.

Model NO. BOP rubber Specification As per Model Trademark Beyond Origin China

Product Description

Beyond is established to offer the best solutions for the overseas customers on drilling equipment and spare parts for different drilling application like petroleum, geothermal, water well and HDD etc.

Beyond possesses strong supply chain, after-sales service and logistics integration capacities and holds exclusive agent rights of multiple firms. Beyond products cover but not limited to: China-make drilling and workover rigs, mud pumps, solid control system and equipment, wellhead and downhole tools, drilling tools, OCTG and other related equipment and parts. Meanwhile, Beyond can offer technical services, personnel training and maintenance guide towards China-made drilling rigs. Only if it is what you need, Beyond can get it for you, with quality assurance, most competitive prices and shortest lead time.

With "professional & efficient, customer focus, win-win cooperation" as its operation principle, Beyond believes that we will become your best cooperative partner in China.

Main technical parameters: Bore: 11"(350mm)   Working pressure: 5000psi(35Mpa)

Characters:
In the structure, it is divided into annular blowout preventer with spherical plastic core, annular blowout preventer with cone-shaped plastic core, and blowout preventer with tube-shaped plastic core. Annular BOP top cap and housing are connected by bolts or claw blocks.
Blowout preventer with spherical plastic core and dust-proof ring.
Performance characteristics: reasonable structure, easy operation, long life of plastic core, adapt to a wide range, capable to seal pipe string with nominal paths from 0-DN in ans shapes, better performance by combining with ran blowout preventer in the use.

Working Principle
When wells must be sealed in case of kicks high pressure (10.5Mpa) oil from control systems enters into close-cavity under piston from housing oil outlet, to promote plastic core moving upward along ball surface, so that bearing tendons move closer to each other to moce the rubber between them to the center of wellhead so as to seal drilling tools or fully seal wellhead. In opening , hydraulic pressure oul enters into open-cavity above piston from housing oul inlet, to push piston moving downwards , so that plastic will reset with its own elasticity, wellhead will be open.
