Crawler Mounted Water Well Drilling Rig Water Well Drilling Machine for Sale

Ji Ning Hengwang Mining Machinery Co., Ltd.
  • After-sales Service：1 Year
  • Warranty：1 Year
  • Certification：CE, ISO 9001:2000, ISO 9001:2008
  • Condition：New
  • Motor：Diesel Engine
  • Drill Hole Diameter：200-250mm

Base Info

  • Model NO.：200m
  • Drill Hole Depth：>200m
  • Bit Type：Hammer Bit
  • Type：Crawler
  • Model：Hqz-180L
  • Overall Weight：3.5t
  • Dimension (mm )：3400*1500*2400
  • Drilling Depth (M)：180
  • Traveling Speed：2.5 Km,H
  • Climbing Ability：2.5
  • Minimum Ground Clearance：250
  • Working Air Pressure：1.45 - 2.5MPa
  • Air Consumption：15-27m³,Min
  • Main Machine Power：42kw
  • Rotary Speed：38 - 80rpm
  • Transport Package：Wood Package
  • Specification：1500*950*950 mm
  • Trademark：HW
  • Origin：China
  • Production Capacity：500,Month

Description

Model

HQZ-180L

Overall weight (T )

3.5

Dimension (mm )

3400*1500*2400

Drilling diameter (mm )

130-245

Drilling depth (m)

180

One-time advance length of the drill(mm)

3000

Traveling speed (km/h )

2.5

Climbing ability (max )

25°

Minimum Ground Clearance (mm)

250

Working Air Pressure (mpa )

1.45 - 2.5

Air consumption(m³/min)

15 - 27

Main machine power (kw)

Yunnei 42Kw

Rotary Speed (rpm)

38 - 80

Rotary torque (Nm)

4000-5000

  Machine picturesCrawler Mounted Water Well Drilling Rig Water Well Drilling Machine for SaleCrawler Mounted Water Well Drilling Rig Water Well Drilling Machine for SaleCrawler Mounted Water Well Drilling Rig Water Well Drilling Machine for SaleCrawler Mounted Water Well Drilling Rig Water Well Drilling Machine for SaleCrawler Mounted Water Well Drilling Rig Water Well Drilling Machine for SaleCrawler Mounted Water Well Drilling Rig Water Well Drilling Machine for Sale
