• Model NO.：SWRDR2600
• Rated Output Torque：2600kn.M
• Max. Pile Diameter：2500 mm
• Speed of Rotation：10.7-22.5
• Engine Power：261kw
• Transport Package：Nude
• Specification：ISO9001
• Trademark：SINOWAY
• Origin：China
• HS Code：84304122
• Production Capacity：20000 PCS Per Year

Basic Info.

Model NO. SWRDR2600 Rated Output Torque 2600kn.M Max. Pile Diameter 2500 mm Speed of Rotation 10.7-22.5 Engine Power 261kw Transport Package Nude Specification ISO9001 Trademark SINOWAY Origin China HS Code 84304122 Production Capacity 20000 PCS Per Year

Product Description

Sinoway treat Service as a significant segment in our value chain, from the moment you get in touch with Sinoway, our commitment to service is a complete guarantee that we will make every effort to be there for you. That is our pledge to you. We wish to not just satisfy but surpass the expectations of our customers.




Performance
Max. drilling diameter	2000 mm
Max. drilling depth	68 m
Applicable longest machine lock type kelly bar	15m*5sections,φ470 Interlocked kelly bar
Max. drilling depth ( with standard kelly bar)	42 m
Specification of standard kelly bar	12m*4sections,φ470 Interlocked kelly bar
Rated output torque	260 kN·m
Max. output torque	265 kN·m
Drilling speed	7~28 rpm
Max. pressurized force of pressurized oil cylinder or pressurized winch	215 kN
Max. lifting force of pressurized oil cylinder or pressurized winch	230 kN
stroke force of pressurized oil cylinder or pressurized winch	5330 kN
Angle of left/right inclination of mast	6°
Angle of forward inclination of mast	5°
Engine
Engine model	Cat C9 ACERT Electronic injection
Power	261 kw
Lifting force of main winch (first layer)	270 kN
Wire rope diameter of main winch	32 mm
Max. lifting speed of main winch	80 m/min.
Lifting force of auxiliary winch (first layer)	120 kN
Wire rope diameter of auxiliary winch	20 mm
Max. lifting speed of auxiliary winch	70 m/min.
Undercarriage
Chassis model	CAT336D (OR CAT330D)
Crawler belt width	800 mm
Equipment width in working state	4300 mm
Equipment height in working state(H)	22580 mm
Equipment length in transporting state(L)	16700 mm
Equipment width in transporting state	3000 mm
Equipment height in transporting state(H)	3420 mm
Chassis length (wheel track)(A)	5000 mm (CAT330D:4600)
Tractive force	510 kN
Fully-cased construction (casing driver)
Applicable longest casing	5000 mm
Applicable longest interlocked kelly bar	11m x 5 - Φ470
Fully-cased construction (using casing ocillator) / Applicable longest casing	according to act ual condition
The standard drilling tools (drilling bucket)	Φ1500 mm
Weight
Total weight (including standard drilling tool)	78 ton
Weight in transporting state	67 ton
