• Model NO.：SWDTH628T
• Drilling Way：Impactor
• Drilling Depth：25 M
• Rock Rigidity：F=6~20
• Diameter：76mm-115mm
• Transport Package：Naked
• Specification：Dia. 76-110mm
• Trademark：Sinoway
• Origin：China
• HS Code：8430412900
• Production Capacity：200 Units,Month

ngineCompressorModelCummins 6BT5.9TypeSix-cylinder, water cooled, turbocharged, mechanical injectionRated power110kwRated speed2200rpmMain Technical SpecificationTracked drilling CarriageRock rigidityf=6 - 20Diameter of drill hole60 - 130mmDepth of drill hole25mTravelling speed3km/hGradeability25°Rotation speed0 - 70rpmWorking pressure0.5 - 1.4MPaAir consumption7 - 12m³/min.CompressorTypeScrew rotating one stage compression oil cooledDisplacement10.2m³/min.Pressure0.7 - 1.0MPaLubricating modeForced lubricating according to lubricating compressionDrive modeCoupler directVolume of lubricating oil60LChassisCompressorTyre size6.5-16Tyre pressure0.6MPaTread1560mmDimensionsTracked drilling CarriageOverall length4250mmOverall width1980mmOverall height2260mmCompressorOverall length3360mmOverall width1850mmOverall height1850mmConnector sizeR1.1/2"x1, R1"x2Max. working altitude3000mWeightTracked drilling Carriage3000kgCompressor2100kgMain FeaturesTracked drilling CarriageSelf-powered high efficiency, energy saving, lower noise, less operation cost, wide range of usage, easy for maintenance, major components such as motor / control valve made in Germany and Japan, large scope amplitude modulation capacity.CompressorAdvanced microprocessor monitoring all changes for compressed air demand, lowering air consumption, motor / mounted roller / ball bearing made in Germany; advanced separator and filter insuring residual oil content less than 3ppm, aluminium radiator easy for cleaning, anti-high temperature pipe and connector prevent oil leakage.Optional10 - 20m³/min. air delivery compressor series Depth of drill hole with 30m / 35m Drilling diameter90 - 130mm
Sinoway treat Service as a significant segment in our value chain. All of our service-related businesses-aftermarket parts, technical support, training, OEM Solutions are based on offering more professional service, extending the life of each machine we delivered.

For special key projects and VIP customers, Sinoway offer on-site field service for a certain period, to allow the team of our users with a better understanding on the operating and maintenance, to help training the service team of their own, or give a proposal on the maintenance solutions according to the special operating environment. With the field service, we are confident to enable our machinery reduce the downtime at maximum and help our clients fulfill the project smoothly and on time.ConditionBrand newWarrantyOne year or 1000 working hours,whichever comes earlierShipment TermFOB, CFR, CIF, CIP, DAF
