30m DTH Surface Mining Blast Hole Quarry Rock DTH Drilling Rig
Ji Ning Hengwang Mining Machinery Co., Ltd.- After-sales Service：1 Year
- Warranty：1 Year
- Certification：CE, RoHS, ISO 9001:2008
- Condition：New
- Motor：Diesel Engine
- Drill Hole Diameter：90-138mm
Base Info
- Model NO.：HW-420
- Drill Hole Depth：30m
- Bit Type：Diamond Bit
- Drilling Way：Impactor
- Model：Hw420
- Drilling Diameter：90-138mm
- Drilling Depth：30m
- Engine：58kw
- Drill Pipe Sizes：76 X 3,000 mm
- Rotation Torque (：2200 N.M
- Rotation Speed：0 -150 Rpm
- Working Pressure：0.7 - 2.5 MPa
- F.a.D：8 - 20 M3,Min
- Feed Force：15kn
- Pull up Force：25kn
- Tramming Speed (Max.)：2.5 Km,H
- Transport Package：Container
- Specification：5700 X 2130 X 2200 mm
- Trademark：Hengwang
- Origin：Shandong, China
- Production Capacity：500 Sets Per Month
Description
Transportation Dimensions
5700 X 2130 X 2200 mm
Detail Photos
Features:
Successful Project Packaging&ShippingDrill rigs are coated with anti-rust liquid naked, drill pipes are bundled and packed, impactors, drill bits and other accessories are packed in plywood boxes.1 Set Shipped with 20GP;
Whole set with air compressor needs a 40GP;
