Drilling Rig

Wider Range of Operating Holes Geotechnical Engineering Drilling Rig

Zhengzhou Hanfa Prospecting Machinery Co., Ltd.
  • After-sales Service:Online Support,Field Maintenance
  • Warranty:1 Year
  • Certification:CE, RoHS, ISO 9001:2000, ISO 9001:2008
  • Condition:New
  • Drill Hole Diameter:50-250mm
  • Drill Hole Depth:100-120m

Base Info

  • Model NO.:Hfmg-120
  • Bit Type:Diamond Bit
  • Drilling Way:Rotary
  • Type:Crawler
  • Drilling Diameter:50-250mm
  • Drilling Depth:100-120m
  • Engine Power:55kw+ 18.5kw + 2.2kw
  • Rotary Torque:6800n·m
  • Power Head Output Speed:15-150r,Min
  • Power Head Stroke:3200mm
  • Lower Bracket Feeding Process:900mm
  • Rated Lifting Force of Power Head:50kn
  • Horizontal Lifting Height:1800-3500mm
  • Weight:7000kg
  • Transport Package:Standard Export Packing or as You Needs
  • Specification:5450*2300*2250mm
  • Trademark:HF
  • Origin:Zhengzhou City, China
  • HS Code:843041
  • Production Capacity:30sets,Month

Description
