• Model NO.：GL520
• Type：Crawler
• Model：Hydraulic Rock Drill 520
• Drilling Diameter (mm)：64-89
• Diameter of Drilling Rod (mm)：Standard -T38, Optional-T45
• Length of Drilling Rod (mm)：3660
• Drilling Rod Exchanger：Optional
• Drilling Depth (M)：18-22
• Engine of Cummins：93kw, 2200r,Min
• Air Compressor：3.4m³,7bar
• Propulsion Method：Motor + Chain
• Propulsion Compensation (M)：1.2
• Usage：Water Well
• Power Type：Diesel
• Transport Package：Standard Export Packing
• Specification：SGS
• Trademark：GLORYTEK
• Origin：China
• Production Capacity：50 Sets Per Month

Basic Info.

Model NO. GL520 Type Crawler Model Hydraulic Rock Drill 520 Drilling Diameter (mm) 64-89 Diameter of Drilling Rod (mm) Standard -T38, Optional-T45 Length of Drilling Rod (mm) 3660 Drilling Rod Exchanger Optional Drilling Depth (M) 18-22 Engine of Cummins 93kw, 2200r/Min Air Compressor 3.4m³/7bar Propulsion Method Motor + Chain Propulsion Compensation (M) 1.2 Usage Water Well Power Type Diesel Transport Package Standard Export Packing Specification SGS Trademark GLORYTEK Origin China Production Capacity 50 Sets Per Month

Product Description

The 520 hydraulic crawler drill owns many advantages, such as steady performance, high speed, strong grade ability, high efficiency, long usage life, energy saving, easy to operate and have the functions of self-diagnosis, self-repair and self-protection. It can be applied to different working conditions to meet different drilling needs.

Model	Hydraulic Rock Drill 520
Drilling Diameter (mm)	64-89
Diameter of Drilling Rod (mm)	Standard -T38 , Optional-T45
Length of Drilling Rod (mm)	3660
Drilling Rod Exchanger	Optional
Drilling Depth (m)	18-22
Engine of Cummins	93kw, 2200r/min
Air Compressor	3.4m³ /7bar
Propulsion Method	Motor +Chain
Propulsion Compensation (m)	1.2
Traveling Speed (km/h)	4
Grade Ability (°)	30
Crawler Swing (°)	+10
Dust Collection Method	Dry-type Dust Collection
Total Weight (kg)	9650
