Belt Vulcanizer for Explosion-Proof Coal Mine

Xibite (Shandong) Precise Machinery Company Limited
  • Warranty：a Year
  • Certification：RoHS, ISO 9001:2000
  • Condition：New
  • Motor：AC Motor
  • Drill Hole Diameter：>300mm
  • Drill Hole Depth：>300m

Base Info

  • Model NO.：LBD-1400
  • Bit Type：Diamond Bit
  • Drilling Way：Rotary
  • Shandong：Dezhou
  • Transport Package：Box
  • Specification：LBD-1400
  • Trademark：XBT
  • Origin：China Dalu
  • HS Code：6210026
  • Production Capacity：50000 a Year

Description

Basic Info.

Model NO. LBD-1400 Bit Type Diamond Bit Drilling Way Rotary Shandong Dezhou Transport Package Box Specification LBD-1400 Trademark XBT Origin China Dalu HS Code 6210026 Production Capacity 50000 a Year

Product Description

Belt Vulcanizer for Explosion-Proof Coal MineBelt Vulcanizer for Explosion-Proof Coal Mine1. Vulcanization pressure: 1.5MPa

2. Vulcanization temperature: 145 ºC

3. Surface temperature difference of vulcanized plate: ± 3 ºC

4. The heating time (from normal temperature to 145 ºC) is not more than 50min

5. Power supply voltage: 380V, 50Hz,

6. Output power of electric cabinet: 36kw,

7. Temperature regulation range: 0 ~ 200 ºC,

8. Timing adjustment range: 0 ~ 59min,

9. After the upper and lower heating plates are pressurized by 0.8 MPa, the gap shall not be greater than 0.5mm
