• Model NO.：LQ360 Crawler Type Auger Drilling Rig
• Usage：Ore, Pile Foundation Hole, Water Well, Coal
• Power Type：Diesel
• Specification：ISO9001: 2008, SGS
• Trademark：csmiracleland
• Origin：Changsha, Hunan, China
• HS Code：8430490000
• Production Capacity：10 Sets,Month

LQ360 Crawler Piling RigItemUnitDataVehicle parametersDimensionsmm7300x2100x2850Minimum gapmm230Upright heightmm7500Telescopic trajectorymm800Total weightkg7200Travel speedKm/h3Grade ability°30Diesel engineModel/Weichai 4105Powerkw88Rotary speedr/min2200Generator setPowerkw40-50Hydraulic systemWedge pressurempa16-20Outrigger pressurempa16-20Max. pressurempa20Main pump flowl/min32Working rangePiling hole diametermm100-800Piling hole depthm6-20Drill pipe speedr/min40-65Drill full forcekn100Rotation angle°360Piling rig performance1 . on the frame and the next frame can be rotated 360 ° , the frame can slide back and forth 80cm. Working without dead ends.
2 . high piling speed, an average of 3 minutes into a 6m deep hole.
3 . Remote piling can use the remote control, the operation easier.
4 . supports two walk way: Hydraulic power walking and walking (with generators).
5 . vehicle parts, electrical products are based on well-known manufacturers, quality is guaranteed.
