DTH Mining Drilling Rig for Rock Borehole Blasting Hole Drill Rigs

Ji Ning Hengwang Mining Machinery Co., Ltd.
  • After-sales Service：Yes
  • Warranty：Yes
  • Certification：CE, ISO 9001:2000, ISO 9001:2008
  • Condition：New
  • Motor：Yuchai
  • Drill Hole Diameter：90-130mm

Base Info

  • Model NO.：HW420
  • Bit Type：Diamond Bit
  • Drilling Way：Rotary
  • Rated Power：58kw
  • Hole Depth：30m
  • Pull up Force：25 Kn
  • Feed Force：15 Kn
  • Rotation Torque (Max.)：2200 N.M
  • Drill Pile Sizes：76 X 3,000 mm
  • Hole Dia：90-130 mm
  • Tramming Speed (Max.)：2.5 Km,H
  • Gradient：25°
  • Total Weight：4000kg
  • Transport Package：Standard Packaging
  • Specification：5700 X 2130 X 2200 mm
  • Trademark：Hengwang
  • Origin：Shangdong
  • Production Capacity：100PCS ,Month

Description

Transportation Dimensions

5700 X 2130 X 2200 mm

DTH Mining Drilling Rig for Rock Borehole Blasting Hole Drill RigsDTH Mining Drilling Rig for Rock Borehole Blasting Hole Drill RigsDTH Mining Drilling Rig for Rock Borehole Blasting Hole Drill RigsDTH Mining Drilling Rig for Rock Borehole Blasting Hole Drill RigsDTH Mining Drilling Rig for Rock Borehole Blasting Hole Drill RigsDTH Mining Drilling Rig for Rock Borehole Blasting Hole Drill RigsDTH Mining Drilling Rig for Rock Borehole Blasting Hole Drill RigsDTH Mining Drilling Rig for Rock Borehole Blasting Hole Drill RigsDTH Mining Drilling Rig for Rock Borehole Blasting Hole Drill Rigs
