• Model NO.：YCR160
• Type：Crawler
• Drilling Depth：53 M
• Products Type：Rock Drill
• Transport Package：Roro
• Specification：13517*3100*3160mm
• Trademark：Yuchai
• Origin：Jiangxu, China
• Production Capacity：1000 Pieces,Per Month

Specificationitem)(Parameters)(Chasis)Engine typeQSF3.8-115/ Power/ revolution86kW/2200rpm()Deployment speed (margin)2600mmTrack shoe width600mmTraction104KN(Power head)The maximum out torque60kN·mPower head revolution0~35rpmThe maximum pressure increased55kNThe maximum pullout force80kNPressurizing oil cylinder stroke1500mm(Winch)(Main winch)Lifting force of the first layer70kNThe maximum lifting speed59m/minSteel wire diameter∅18mmAuxiliary winchLifting force of the first layer15kNThe maximum lifting speed50m/minSteel wire diameter∅12mm(Mast)Front inclination angle of mast5°Left and right inclinations of mast±4°(Hydraulic pump)The maximum working pressure of system32MPa(Hole depth
and diameter)The maximum drilling diameter1.2mThe maximum drilling depth28m/22m(4/3)Weight at working state20 t()15.7t()19tDrill pipe(The standard configuration)∅299-4x7.6 m(optional configuration )∅299-3x7.6 m













Chassis

 mature chassis used is made by using worldclass technology, stable and reliable.
Engine
Engine provided is Com B3.9-C turbocharged engine imported with original packaging, and is trustworthy.
Main winch
It is provided with the complete set of imported  hydraulic system assembly, which makes the main winch high-efficiency and powerful.
Auxiliary winch
It has auxiliary winding function, which makes construction conveniently.
Mast
It is one of main components of rotary drilling rig, is main body of suspending and guiding working device; the equipment has function of automatically making mast upside down, and is equipped with reinforced type mast, and service life of mast can be ensured.
Oil cylinder
Specially-equipped oil cylinder used for pressurizing can make drilling powerful, and travel after pressurizing reach to 1500mm
