• Model NO.：SWCDR200
• Drilling Way：Compound
• Engine Make：Cummins
• Engine Power：74kw
• Max. Drilling Depth：350m
• Color：Yellow
• Lifting Capacity：18kn (4046 Lbf)
• Transport Package：Nude
• Specification：ISO9001
• Trademark：SINOWAY
• Origin：China
• HS Code：84314990
• Production Capacity：3000 PCS Per Year

Basic Info.

Model NO. SWCDR200 Drilling Way Compound Engine Make Cummins Engine Power 74kw Max. Drilling Depth 350m Color Yellow Lifting Capacity 18kn (4046 Lbf) Transport Package Nude Specification ISO9001 Trademark SINOWAY Origin China HS Code 84314990 Production Capacity 3000 PCS Per Year

Product Description

SWCDR200 full hydraulic power head core drilling rig is a light full hydraulic core drilling rig specially designed for complex terrain and inconvenient traffic areas. It is mainly suitable for diamond rope core drilling technology. The main engine includes diesel engine power drill, hydraulic system, control system, main hoist, rope core hoist, power head, feed system and wellhead gripper. All functions of SWCDR200 fully hydraulic surface coring rig are hydraulic driven. It has the characteristics of strong disassembly, light weight of disassembly parts, simple assembly, convenient operation, precise control, convenient removal and high efficiency of coring operation.

Highlights

With the hydraulic pressure system adopted threshold power control and negative flow control,the system acquired high efficiency and higher energy conservation.

Using single rope winding, effectively solve the steel wire rope wear problem, improve the life of wire rope; And drill deep detection device is setted in main winding,single rope to make deep inspection more accurate.

The standard centralized lubrication system, maintenance more convenient.

Several drilling rod configurations with different specification are available for efficient construction on different layers.

The detachable unit head drive key can provide easy maintenance and replacement.
