200m Depth DTH Hammer Borehole Drilling Machine for Water in China

Ji Ning Hengwang Mining Machinery Co., Ltd.
  • After-sales Service：Support
  • Warranty：1 Year
  • Certification：CE, RoHS, ISO 9001:2000, ISO 9001:2008
  • Condition：New
  • Motor：DC Motor
  • Drill Hole Diameter：250-300mm

Base Info

  • Model NO.：HQZ220L
  • Drill Hole Depth：>200m
  • Bit Type：Diamond Bit
  • Drilling Way：Impactor
  • Type：Crawler
  • Name：Drilling Rig
  • Drilling Depth：220m
  • Drill Diameter：245mm
  • Color：Customized
  • Power：60kw
  • Transport Package：Container
  • Specification：3400*1500*2400 mm
  • Trademark：HW
  • Origin：China
  • HS Code：8430419000
  • Production Capacity：100 Sets,Month

Description

Application200m Depth DTH Hammer Borehole Drilling Machine for Water in China200m Depth DTH Hammer Borehole Drilling Machine for Water in China
Specification

Model

HQZ220L

Overall weight (T )

4.2

Dimension (mm )

3800*1700*2350

Drilling diameter (mm )

130-294

Drilling depth (m )

220

One-time advance length of the drill(mm)

3000

Traveling speed (km/h )

2.5

Climbing ability (max )

30

Minimum Ground Clearance (mm)

250

Working Air Pressure (mpa )

1.7-2.5

Air consumption (m³/min)

15-27

Main machine power (kw)

Yunnei 60Kw

Rotary Speed (rpm)

48 - 70

Rotary torque (Nm )

4200-5600

Products Details200m Depth DTH Hammer Borehole Drilling Machine for Water in China200m Depth DTH Hammer Borehole Drilling Machine for Water in China
Packing and delivery200m Depth DTH Hammer Borehole Drilling Machine for Water in China



Our factory

200m Depth DTH Hammer Borehole Drilling Machine for Water in China
