Best Price Environmental Protection Soil Core Sampling Investigation Drill Rig for Civil Foundation
Ji Ning Hengwang Mining Machinery Co., Ltd.- After-sales Service：Support
- Warranty：2 Years
- Condition：New
- Motor：DC Motor
- Drill Hole Diameter：<100mm
- Drill Hole Depth：30-50m
Base Info
- Model NO.：HWED50
- Bit Type：Drag Bit
- Drilling Way：Rotary
- Transport Package：Load in Container
- Specification：2600 *950 *1700 mm
- Trademark：Hengwang
- Origin：Shandong, China
- HS Code：8430419000
- Production Capacity：500set,Year
Description
Model
HWED50
Core depth(m)
0-50
Drilling form
Direct push
Casing diameter (mm)
52/63/76/95
Sampling diameter (mm)
38/52/65/70
DTH depth (m)
0-200
Drilling diameter (mm)
38-180
Effective stroke (mm)
1650
Engine(kw r/min)
Joint venture brand 40KW/3000
Hydraulic pump
Imported plunger pump
Multi-way valve
imported
Whole machine oil pipe
Horse Brand (Germany)
Maximum lifting force(t)
10
Drilling force(t)
0-6.5
Direct frequency(bmp)
600-2000
Walking motor
import
Transport size(mm)
2600*950*1700
Maximum working size(mm)
2550*950*4220
Total Weight(T)
1.8
Walking speed(kmZh)
0-5 (high and low speed)
Maximum climbing angle(°)
35
Remote control
Optional function
