• Model NO.：20m
• Drill Hole Depth：20m
• Bit Type：Diamond Bit
• Drilling Way：Rotary
• Rated Power：191kw
• Hole Depth：20m
• Pull up Force：25 Kn
• Feed Force：15 Kn
• Rotation Torque (Max.)：1,650 N.M
• Drill Pile Sizes：60*2000 mm
• Hole Dia：90-110 mm
• Tramming Speed (Max.)：2.5 Km,H
• Gradient：25°
• Total Weight：93
• Transport Package：Standard Packaging
• Specification：7, 550X2, 500X3, 060 mm
• Trademark：Hengwang
• Origin：Shangdong
• Production Capacity：100PCS ,Month

Main technical specifications

Power

Yuchai YC6J220 162 kW

Hole Depth

20m

Drill Pile Sizes

60 mmX3000 mm

Hole Dia

80-115mm

DTH Hammer

3.5"

Rotation Torque (Max.)

1650N.m

Rotation Speed

0-110 rpm

Working Pressure

14.5 bar

F.A.D

12 m3/min

Tramming Speed (Max.)

2/3 km/h Dual Speed

Gradient

30°

Track Frame Oscilation

±10°

Total Weight

6,800 kg

Transportation Dimensions

6,000X2,800X2,750 mm

Dry Dust Collector

Standard

Dual Speed Walking Motor

Standard
