• Model NO.：HFX300
• Drill Hole Depth：300m
• Bit Type：Diamond Bit
• Drilling Way：Rotary
• Type：Crawler
• Driling Depth：300m
• Max. Diameter of Working Floor：∅400mm
• Max. Lifting Capacity：280kn
• Max.Feeding Capacity：120kn
• Max.Lifting Speed：30m,Min
• Max.Feeding Speed：60m,Min
• Max. Pressure：4(Optional)L,Min
• Pressure：8MPa
• Transportation Dimension(L*W*H)：6100mm*2100mm*2690mm
• Weight：12t
• Transport Package：Standard Export Packing or as You Needs
• Specification：CE, ISO
• Trademark：HANFA
• Origin：Zhengzhou City, China
• HS Code：843041
• Production Capacity：30sets,Month

Product Parameters

Type

HFX500

Drilling capability

Driling depth

m

500(∅89)

Max. diameter of working floor

mm

∅400

Feeding system

Max. lifting capacity

KN

280

Max.feeding capacity

KN

120

Max.lifting speed

m/min

30

Max.feeding speed

m/min

60

Stroke

mm

7000

Top drive

Max.torque

N.M

9200/4600

Max.Speed

r/min

95/190

I.D

mm

∅55

Floating distance

mm

/

Max.tilting angle

°

/

Deck engine

Type

YC6J175-T302

Rated power

kw

129

Main winch

Hoisting capacity

/

Tool winch

Hoisting capacity

KN

15

Breakout device

Max.breakout torque

KN

/

vise clamping range

N.M

/

Foam pump

Max. flow

mm

35(Optional)

Max. pressure

L/min

4(Optional)

Mud pipe

I.D

mm

∅55

Max. pressure

Mpa

8

Chassis

Drive mode

Mpa

Crawler chassis

Rated power

kw

/

High speed

km/h

2

Max.climbing gradient

%

39

Working dimension(L*W*H)

mm

5100 x 3200 x 9800

Transportation dimension(L*W*H)

mm

6100 x 2100 x 2690

Weight

t

12

1. Are you a trading company or a manufacturer?
We are a professional manufacturer. Our factory mainly produces water well drilling rigs, core drilling rigs, down-the-hole drilling rigs, pile drivers, etc. The products have been exported to hundreds of countries around the world and enjoy a high reputation all over the world.

2. How is the quality of your machine?
Our products pass strict quality inspections before they leave the factory to ensure that they are qualified before they are shipped.

3. How to inspect the goods?
1) Support customers to come to the factory for on-site inspection.
2) Support customers to designate third-party companies to inspect goods.
3) Support video inspection.

4. Do you have after-sales service?
Yes, we have a dedicated service team that will provide you with professional technical guidance. If you need, we can send our engineers to your workplace and provide training for your employees.

5. How about quality assurance?
We provide a one-year quality guarantee for the main machine of the machine.

6. How long is your delivery cycle?
1) In the case of stock, we can deliver the machine within 7 days.
2) Under standard production, we can deliver the machine within 15-20 days.
3) In the case of customization, we can deliver the machine within 20-25 days.
