Diamond Core Drilling Rig Forward C5
Lianyungang Forward Heavy Industrial Machinery Co., Ltd.- Certification：CE, ISO9001:2015
- Condition：New
- Motor：Diesel Engine
- Drill Hole Diameter：100-150mm
- Drill Hole Depth：>300m
- Bit Type：Diamond Bit
Base Info
- Model NO.：C5
- Drilling Way：Rotary
- Transport Package：Nude Packing
- Specification：5920x2250x2505 mm
- Trademark：FORWARD
- Origin：Lianyungang, China
- HS Code：8430412900
- Production Capacity：48
Description
Dry holeFluid Filled Drill Rod/Core Barrel Hole Depth (Meters) Hole Depth (Feet) Hole Depth
(Meters) Hole Depth (Feet) BRQ/BQ 1310 4298 1500 4920 BRQTK/BQTK 1648 5400 1880 6170 NRQ/NQ/NQ2 1006 3300 1151 3800 NRQ V-WALL 1139 3700 1291 4230 HRQ/HQ 683 2240 781 2560 HRQ V-WALL 860 2800 972 3180 PHD/PQ 451 1480 515 1690 PHD V-WALL 615 2010 690 2260
Reliable Components:
1 MAST:
Rigid design of the mast provides superior performance and reliability even under the toughest geological conditions. Separate allocation of operator work place and mast lift/ extend control valve seriously reduces malfunction during work.
The telescopic mast ensures the reliability of drilling. The underside end of the drilling mast anchors the ground surface while drilling, providing with additional stability. While transportation the mast can be moved to center of gravity of the rig for more safety.
2 OPERATOR PANEL:
While transportation the operator panel is in closed position in order to avoid breakdowns.
The operator panel is equipped with non-fixing control joysticks, which provide additional safety for the operator. Drilling and rotation joystick with friction damper and non-fixing hoist, Joystick provides convenience and safe operation. There is auto alarm function for low level of hydraulic oil.
3 HOOD:
Fiberglass hood provides excellent sound and heat insulation. Hood tilts with two fixing hydraulic props, which ensure easy access to maintenance of engine and hydraulic system.
4 HYDRAULIC SYSTEMS:
Hydraulic pumps are directly connected to PTO-driven auxiliary pump, ensuring easy maintenance.
5 DRILL HEAD:
Drill head is suitable for drilling with rods of B-P series, rod's diameter arranges from 55.5mm to 114,3mm, inner diameter of main axle is 121mm.
Patented jaws with chuck and hydraulic opening/spring closing function insure fail-safe operation. Spring clap and disk chuck clutch drill rods securely.
Drill head with direct drive from hydraulic cylinder ensures stability during drilling process, as well as more accurate and reliable pressure regulation while drilling with pressure increase or decrease.
6 OIL COOLING RADIATORS:
Separately located radiator has fan adjustment function according to environment temperature.
Radiators placed along increase the hydraulic oil's cooling efficiency. The drill head is equipped with a separate radiator.
7 MAIN WINCHES:
Mounting of main winch on mast minimizes coring drill rig's vibration.
8 CRAWLER CHASSIS:
Crawler chassis of the drill rig is equipped with hydraulic motors of Korean, which guarantee high operation quality.
To learn more details, please do not hesitate to contact us ASAP.
