All Famous Brand Zoomlioin Xccg Yuchai Saay Rototary Drilling Rig
Maxizm Construction Machinery (Qingdao) Co., Ltd.- After-sales Service：Support
- Warranty：Support
- Certification：CE, RoHS, ISO 9001:2000, ISO 9001:2008
- Condition：New
- Drill Hole Diameter：1500mm
- Drill Hole Depth：30-50m
Base Info
- Model NO.：YCR120
- Bit Type：Diamond Bit
- Drilling Way：Rotary
- Type：Crawler
- Product Name：Rotary Drilling Rig
- Model：Ycr120
- Max.Output Torque：120kn.M
- Speed of Rotation：8~28rpm
- Engine Model：6bt5.9-150
- Rated Power：112kw,1950rpm
- Working Pressure：34MPa
- The Length of Crawler：4446mm
- Rated Production Capacity：10units,Month
- Diameter of The Steel Wire Rope：16mm
- Transport Package：Null
- Specification：12630x2990x3350mm
- Trademark：Yuchai
- Origin：Guangxi, China
- HS Code：8430509000
- Production Capacity：1000,Year
Description
Overview
Contact wayYUCHAI MODEL YCR50 YCR120 YCR180 YCR220 Max. pile Diameter(mm) 1200 1500 1800 2500 Max. pile Depth(m) 23 40 59.3 82 Max.output torque(kN m) 50 120 180 260 Speed of rotationrpm 6-35 8~28 7~26 6~24 Engine model CU-MMINS B3.9 CU-MMINS 6BT5.9-150 CU-MMINS 6C8.3 CU-MMINS QSM11-C330 Rated power (kw/rpm) 86/2200 112/1950 186/2,200 246/2,100 Working pressure(Mpa) 34 34 34 34 Diameter of the steel wire rope(mm) 16 16 26 32 The length of crawler (mm) 4310 4446 5538 5816 Track shoe width(mm) 600 600 700 800 Operating weight (t) 18.2 35t 64.2 81.1 Transport Dimensions (LxWxH/mm) 9950x2600x3480 12630x2990x3350 14320x3200x3512 16165x3300x3510
