• Model NO.：ZTQD-120
• Drilling Way：Rotary
• Material：Cast Iron
• Air Pressure：0.6-0.8MPa
• Drilling Diameter：65-130mm
• Drilling Depth：Less Than 30m
• Power Driven：Air Compressor
• Transport Package：Wooden Box
• Specification：4 cubic meters
• Trademark：ZHONGTUO
• Origin：China
• HS Code：8430390000
• Production Capacity：50piecces,Month

Basic Info.

Model NO. ZTQD-120 Drilling Way Rotary Material Cast Iron Air Pressure 0.6-0.8MPa Drilling Diameter 65-130mm Drilling Depth Less Than 30m Power Driven Air Compressor Transport Package Wooden Box Specification 4 cubic meters Trademark ZHONGTUO Origin China HS Code 8430390000 Production Capacity 50piecces/Month

Product Description

Description of Down the hole drilling|rotary|diamond hammer

QD-100 Electric DTH Drill is a new, efficient and semi-mechanized advanced rock drilling equipment designed by our own factory.

Structural components

The drill tool consists of drill pipe, ball - tooth bit and impactor. When drilling, drill with two drill pipes. The rotary air supply mechanism is composed of a rotary motor, a rotary reducer, and a wind supply gyroscope. The rotary speed reducer is an anisotropic member enclosed by a three - stage cylindrical gear. The air supply rotary device is composed of connecting body, sealing parts, hollow spindle and drill pipe joint. The lifting pressure regulating mechanism is realized by the lifting motor with the help of the lifting reducer, lifting chain and the rotary mechanism and the drilling tool. In the closed chain system, the pressure regulating cylinder and the movable pulley group are installed. When working normally, the piston rod of the pressure regulating cylinder pushes the movable pulley group to make the drill tool realize the pressure relief drilling.

Use and Characteristic

1. The submersible drilling rig USES the motor through high-performance reducer for rotary power; The cylinder is used for propulsion. The hydraulic system is omitted, so the mechanical efficiency is high, the cost is low and the performance is stable.

2. With anti-card protection, the motor will not burn down or the reducer will not damage when the drill tool is stuck.

3. It is portable and easy to be moved. The weight of the whole drill for underground drilling is less than 500Kg, and it can be decomposed into three pieces.

4. Adopt rolling drag plate, which makes track not easy to wear.

5. The submerged drilling rig adopts semi-automatic removal of drill pipe, with high working efficiency.


Parameters of Down the hole drilling:

model	Q-100
Voltage	380V
Air pressure	0.6-0.8mpa
Drilling diameter	65-130mm
Motor Power	4.0kw
Drilling direction	0°-90°
Hose Diameter	38mm
Drilling depth	≥30m
Cylinder advance stroke	1000
