Portable Xy-400f Well Drilling Rig Manufacturer
Zhengzhou Defy Mechanical & Electrical Equipment Co., Ltd.- Condition：New
- Drill Hole Depth：400m
- Bit Type：Diamond Bit
- Drilling Way：Rotary
- Type：Four-Wheel trailer
- Max. Depth：400m
Base Info
- Model NO.：XY-400F
- Borehole Caliber Range：75-600mm
- Application：Various Soft and Hard Rock, Water Well Drilling Ri
- Control System：Hydraulic Control System
- Tower：Telescopic Type
- Transport Package：Standard Export Packing
- Specification：BV&SGS&ISO
- Trademark：DEFY
- Origin：Zhengzhou, Henan Province, China
- HS Code：8430490000
- Production Capacity：200 Sets,Month
Description
1. Main ParametersMax. Drilling Depth 400m Diameter of drill pipe Φ42,Φ50,Φ60,Φ76 Angle of vertical spindle 0°~90° Drilling capability Φ75mm drill diameter 400m depth Φ108mm drill diameter 320m depth Φ127mm drill diameter 280m depth Φ168mm drill diameter 220m depth Φ219mm drill diameter 160m depth Φ273mm drill diameter 130m depth Φ400mm drill diameter 100m depth Φ500mm drill diameter 50m depth Φ600mm drill diameter 30m depth
3. advantages
1.XY-400f adopts the newest automobile transmission assembly, with 8 grades forward rotation speed and 2 grades reverse rotation speed, reasonable design, wide speed adjustable range, can meet various stratum drilling requirements.
2. Can meet the demand for various high efficiency drilling process needs, such as diamond wireline coring, impact drilling, directional drilling, reverse circulation continuous coring (sampling) etc.
3. Strong power, strong torque, strong bearing capacity, convenient to solve different downhole accidents. Compact mechanical transmission structure, light weight, large diameter of spindle bore, hydraulic stabilizer legs, good rigidity .
4.Package:
Size: 3980*1950*2750mm
weight: 3000kg
Package details: main machine naked into 20feet container,spare parts in wooden case
5.Service:
Pre sales service:
Inquiry and consulting support
view our Factory
After sales service:
training how to install the machine,how to use in our factory
engineer available to service machine overseas
6. DEFY Company
Zhengzhou DEFY is recognized world-wide as the industry leader in exploration drilling technology. Manufacturing water well drill, diamond core drills for a broad range of surface applications, we offer solutions for shallow and deep hole drilling with small or large diameter for both wireline and conventional drilling, and a variety of mounting options such as trailer, crawler, truck mount and flyable versions to suit many applications.
7. Contact
Anne Bai
Zhengzhou DEFY Mechanical&Electrical Equipment Co., Ltd
ADD: No. 96 Ruida Road, High-Tech Zone, Zhengzhou,China
Office Tel: 86-371-55819257
Mobile phone:86-15136212564
Website: defydrillingrig.en.made-in-china.com
defydrillingrig.en.made-in-china.com
