High-Performance Hydraulic System and Control System Drilling Rig

TYSIM Piling Equipment Co., Ltd.
  • Certification：CE, ISO 9001:2000
  • Condition：New
  • Drill Hole Diameter：>300mm
  • Drill Hole Depth：30-50m
  • Drilling Way：Rotary
  • Type：Crawler

Base Info

  • Model NO.：KR165C
  • Torque：165 Kn.M
  • Max. Diameter：1500mm
  • Max. Drilling Depth：56 M
  • Max. Crowd Pressure：155 Kn
  • Max. Crowd Pull：160 Kn
  • Main Winch Line Pull：160 Kn
  • Operating Height：19152mm
  • Operating Width：4100mm
  • Transport Package：Bulk Pack
  • Specification：49 t
  • Trademark：tysim
  • Origin：Jiangsu, China
  • HS Code：8431499900
  • Production Capacity：30pieces,Month

Description

Basic Info.

Model NO. KR165C Torque 165 Kn.M Max. Diameter 1500mm Max. Drilling Depth 56 M Max. Crowd Pressure 155 Kn Max. Crowd Pull 160 Kn Main Winch Line Pull 160 Kn Operating Height 19152mm Operating Width 4100mm Transport Package Bulk Pack Specification 49 t Trademark tysim Origin Jiangsu, China HS Code 8431499900 Production Capacity 30pieces/Month

Product Description

High-Performance Hydraulic System and Control System Drilling Rig
Technical Specification
TypeKR165C
Torque165 KN.m
Max. diameter1500 mm
Max. drilling depth46 m
Speed of rotation7~28 rpm
Max. crowd pressure155 kN
Max. crowd pull160 kN
Main winch line pull160 kN
Main winch line speed80m/min
Auxiliary winch line pull60 kN
Auxiliary winch line speed70m/min
Stroke(crowd system)4200mm
Mast inclination(lateral)±3°
Mast inclination(forward)5°
Max. operating pressure35 MPa
Pilot pressure4 MPa
Track shoe width700 mm
Operating height19152 mm
Operating width4100mm
Transport height3321 mm
Transport width3100 mm
Overall weight49 t
High-Performance Hydraulic System and Control System Drilling Rig

High-Performance Hydraulic System and Control System Drilling Rig

High-Performance Hydraulic System and Control System Drilling Rig

High-Performance Hydraulic System and Control System Drilling RigHigh-Performance Hydraulic System and Control System Drilling Rig
High-Performance Hydraulic System and Control System Drilling Rig
Why Choose Us?
1. We are the professional & trustworthy manufacturer of piling machinery in China, best quality & best service.
2. Supply professional customized service to meet all your requirements.
3. Our rotary drilling rigs have been sold to more than 20 counstries, such as Russia, Australia, Thailand, Zambia and others.
4. Competitive price.

FAQ

Q1: What is the Warranty of the Rotary Drilling Rig?

The warranty period for new machine is half a year or 1000 working hours, whichever comes first will be applied.

Please contact with us for detailed Warranty Regulation.

Q2: What's your service ?

We can offer professional technical support and good after-sale service to you.

Modification methods will be different according to different models and configurations of your owned excavators.

Before modifying, you need to provide configuration, mechanical and hydraulic joints and others.

Before modifying, you need to confirm technical specification.
