Mountain Portable Handheld Soil Investigation Drill Rig
Qingdao Bohwa Machinery Corporation- After-sales Service：Available
- Warranty：6 Months
- Condition：New
- Motor：Diesel or Petrol Engine
- Drill Hole Diameter：38-75mm
- Drill Hole Depth：<30m
Base Info
- Model NO.：GP20,GP25,GP50
- Bit Type：Diamond Bit
- Drilling Way：Rotary
- Engine：Gasoline Engine
- Weight：30-165kg
- Stratum：Soil with Some Rocks
- Transport Package：Wooden Case
- Specification：390X360X1200MM
- Trademark：Bohwa
- Origin：China
- HS Code：84304900
- Production Capacity：50sets,Month
Description
Basic Info.
Model NO. GP20/GP25/GP50 Bit Type Diamond Bit Drilling Way Rotary Engine Gasoline Engine Weight 30-165kg Stratum Soil with Some Rocks Transport Package Wooden Case Specification 390X360X1200MM Trademark Bohwa Origin China HS Code 84304900 Production Capacity 50sets/MonthProduct Description
Mountain Portable Handheld Soil Investigation Drill RigI. Product Details
Mountain drilling rigs are mainly suitable for exploration drilling on complex surfaces such as mountains, loess plateaus, hills, Gobi, and farmland. The drilling rig is driven by full hydraulic pressure, and air drilling and air shock drilling are mainly used in mountainous areas. In other areas, auger drilling can be achieved by replacing drilling tools, and mud drilling can be achieved by adding mud pumps. The best frame combination method, fast and convenient combination and disassembly, easy to relocate. Detachable independent frame modules, suitable for human lift or helicopter hoisting. The modular quick release structure is combined with a variety of drilling processes.
II. Technical Specification
| Model No. | GP-50 | GP-25 | GP-20 |
| Installation Type | Rig Stand Platform | Rig Stand Platform | Both Handheld and Rig Stand Platform |
| Drill Borehole Dia. | 75MM | 46MM | 38MM |
| Drill Borehole Depth | 30M | 25M | 20M |
| Drill Rod Dia. | 42MM or 30MM | 30MM | 25MM |
| Roatation Speed (Max. Power) | 353RPM(Low) / 740RPM(High) | 454RPM(Low) / 963RPM(High) | 1660RPM |
| Roatation Speed (Max. Torque) | 255RPM(Low) / 535RPM(High) | 228RPM(Low) / 695RPM(High) | 1200RPM |
| Max. Torque | 180N.M (Low Speed) | 127N.M (Low Speed) | 75N.M |
| Power | 6KW, 3600RPM | 4KW, 3600RPM | 3KW, 3600RPM |
| Engine Type | Diesel or Petrol | Diesel or Petrol | Diesel or Petrol |
| Dimension | 680X1200X1900MM | 740X530X1600MM | 390X360X1200MM |
| Weight | 165KG | 60KG | 30KG |
