• Model NO.：HDD-45G
• Type：Crawler
• Rig Weight：4000-14270 Kg
• Max. Push Force：406kn
• Max. Pull Force：812kn
• Max. Push&Pull Speed：45 M,Min
• Engine Power：179 Kw
• Caterpillar Walking Speed：3-5(Km,H)
• Entry Drill Angle：12°-25°
• Max. Aperture Diameter：1300mm
• Max. Torque：17000 Nm
• Max. Rotation Speed：135 R,Min
• Max. Mud Pump Flow：450 L,Min
• Max. Mud Pump Pressure：8 MPa
• Max. Climbing Gradient：18°
• Max. Crossing Length：50-600m
• Dimension(L*W*H)：7300,8200*2250*2270(mm)
• Transport Package：Seaworthy Packing
• Specification：Max. Torque: 5000-17000Nm
• Trademark：Bohwa
• Origin：China
• HS Code：84254210
• Production Capacity：30sets,Month

Basic Info.

Model NO. HDD-45G Type Crawler Rig Weight 4000-14270 Kg Max. Push Force 406kn Max. Pull Force 812kn Max. Push&Pull Speed 45 M/Min Engine Power 179 Kw Caterpillar Walking Speed 3-5(Km/H) Entry Drill Angle 12°-25° Max. Aperture Diameter 1300mm Max. Torque 17000 Nm Max. Rotation Speed 135 R/Min Max. Mud Pump Flow 450 L/Min Max. Mud Pump Pressure 8 MPa Max. Climbing Gradient 18° Max. Crossing Length 50-600m Dimension(L*W*H) 7300/8200*2250*2270(mm) Transport Package Seaworthy Packing Specification Max. Torque: 5000-17000Nm Trademark Bohwa Origin China HS Code 84254210 Production Capacity 30sets/Month

Product Description

Application:

We have a series of small Horizontal Directional Drilling Rig, ranging from 10T to 35T.With Bohwa HDD rigs pipelines can be installed rapidly, economically and with minimized impact on environment and existing infrastructure.

Specifications:



Name	Specification
Model	HDD45G
Weight	12820/14270 kg
Dimensions	7300/8200*2250*2270(mm)
Max. Push&Pull Force	406/812 kN
Max. Torque	17000 N·m
Max. Push&Pull Speed	45 m/min
Max. Rotation Speed	135 r/min
Engine Power	179 kW
Max. Mud Pump Flow	450 L/min
Caterpillar Walking Speed	3-5(km/h)
Max. Mud Pump Pressure	8 Mpa
Entry Drill Angle	12°-25°
Max. Climbing Gradient	18°
Max. Aperture Diameter	ø1300mm
Max. Crossing length	600m
