High Efficiency 180m Depth Water Well Drilling Rig

Shandong JK Machinery Co., Ltd.
  • Certification:CE, ISO 9001:2008
  • Condition:New
  • Motor:DC Motor
  • Drill Hole Diameter:140-25mm
  • Drill Hole Depth:180m
  • Bit Type:Diamond Bit

Base Info

  • Model NO.:JK-DR180
  • Drilling Way:Rotary
  • Type:Crawler
  • Usage:Water Well
  • Voltage:24V
  • Weight:4.5t
  • Warranty:1 Year
  • Power Type:Diesel
  • Product Name:Water Well Drilling Rig
  • Transport Package:20gp
  • Specification:3800*1500*2200mm
  • Trademark:SDJK
  • Origin:Shandong
  • HS Code:8430412100
  • Production Capacity:100 Pieces,Month

Description

Basic Info.

Model NO. JK-DR180 Drilling Way Rotary Type Crawler Usage Water Well Voltage 24V Weight 4.5t Warranty 1 Year Power Type Diesel Product Name Water Well Drilling Rig Transport Package 20gp Specification 3800*1500*2200mm Trademark SDJK Origin Shandong HS Code 8430412100 Production Capacity 100 Pieces/Month

Product Description

JK-DR180 Water Well Drilling Rig Pneumatically Drilling Depth 180M High Efficiency 180m Depth Water Well Drilling Rig
High Efficiency 180m Depth Water Well Drilling Rig
The JK-DR180 pneumatic DTH drilling rig is capable of drilling upto 160mm diameter holes for pore-forming purposes to a depth of 180 meters.
JK-DR180 new generation multi-purpose DTH deep water well drilling rig is our independent research and development products. These new generation DTH are coupled to higher air power, and thus play a significant role in leading to faster drilling rates.
Adopting newest model & advanced hydro technology, our water well drilling machine are mainly used for well drilling in resource exploration and hydrology wells, civil use water well,  agriculture irrigation project, and can also be used for coal-mine gas exploitation, coalbed methane, shallow layer of shale gas, terrestrial heat, or salvage work.
Made from high quality materials, with fashion and compact design, that keeps our drilling rigs more efficiency and with low failure rate, more economic and durable, and with a high comprehensive cost performance. Our water drilling rigs have received the real market validation as the majority of our customers' positive feedback. High Efficiency 180m Depth Water Well Drilling Rig
ModelJK-DR180
Weight4.5T
Bore diameter140-254mm
Drilling depth180m
Stroke3.4m
Travelling speed2.5km/h
Gradeability30%
Power 55KW
Rated pressure1.7-2.5mpa
Air consumption17-31m³/min
Drill rod diameterΦ76 Φ89
Drill rod length1.5m 2.0m 3.0m
Elevating capacity15T/15KN
Swing speed45-65rpm
Swing torque3200-4600N.M
Dimensions3800*1500*2200mm
