Integrated Blasting Drilling Rig Driven by Diesel

Luohe Quality Mechanical Equipment Co., Ltd.
  • After-sales Service：Online Support
  • Warranty：12 Months
  • Certification：CE
  • Condition：New
  • Motor：DC Motor
  • Drill Hole Diameter：90-110mm

Base Info

  • Model NO.：452H
  • Drill Hole Depth：250-300m
  • Bit Type：Diamond Bit
  • Drilling Way：Rotary
  • Rated Power：36.8kw
  • Drill Pipe Size：60X2000mm
  • Hole Range：90-110mm
  • Rotation Speed：70-150rpm
  • Feed Force：15kn
  • Pull up Force：25kn
  • Weight：3600kg
  • Transport Package：Wooden Box
  • Specification：4900x2000x2200
  • Trademark：QT
  • Origin：China
  • HS Code：8430412900

Description

Overview

Product Description

Product Parameters

ModelZGYX-452ZGYX-452HPowerYuchai YC6A-260LYuchai YCA27240-T300Rated Power191kw176kwDrill Pipe Size76x3000mmHole Range90-138mm90-130mmRotation Speed0-100rpm0-92rpmMax Rotation Torque2500N.m1900N,mWorking Pressure17bar18barF.A.D16m3/min15m3/minMax Tramming Speed3km/h3.3km/hGradient25degreeWeight9310kg10000kgTransportation Dimensions
 7550x2500x3060mm9000x2360x3000mm

Packaging & Shipping

Integrated Blasting Drilling Rig Driven by Diesel

Company Profile

Integrated Blasting Drilling Rig Driven by Diesel

After Sale Service

  1. FAQ

    Integrated Blasting Drilling Rig Driven by Diesel
