• Model NO.：XY-200F
• Bit Type：Diamond Bit
• Drilling Way：Rotary
• Type：Rotary Drilling Rig
• Power：22HP or 15kw
• Mud Pump：Bw-160
• Weight：1700kgs
• Operation：Manul and VCD
• Complete Set：with All Necessary Accessories
• Usage：Water Well
• Power Type：Diesel
• Transport Package：Wooden Package
• Specification：XY-200F
• Trademark：defy
• Origin：China
• HS Code：84304900
• Production Capacity：50 Set Per Month

1.Overall parameters

Drilling depth

200m

Maximum open hole caliber

400mm

End hole caliber

75mm

Diameter of drill rod

50mm

Drilling angle

90~75

Weight(not include power)

760kg

Dimension

2750*950*1600mm

2. Vertical shaft

Rotating speed

71,142, ,310,,620r/min

Feeding stroke

450mm

3.Hoist

Max. single line hoisting capacity

2400Kg

Diameter of wire rope

13mm

Volume of winding drum

35m

Hug floodgate caliber

230mm

Hug floodgate belt width

70mm

4.Mud pump

Type

Horizontal single urn twin-action

Rate of flow

180L/min

MAX. pressure

1.5MPa

Working pressure

0.7MPa

Diameter of  water inlet tube

50mm

Diameter of  water outlet tube

45mm

5.Power

Diesel engine

22HP, 2200r/min

Remarks: Our engineers will help to create a complete set of Borehole drilling machine and drilling tools to ensure your direct use when shipping to your site. For more details, please kindly send us an inquiry or contact our sales people by instant messenger. Thank you for your time. ^_^
