2022 New Design Sr400r-W10 Rotary Drilling Rig for Sale
Cruking Engineering Equipment (Xiamen) Co., Ltd.- After-sales Service：1year
- Warranty：1year
- Certification：CE, RoHS, ISO 9001:2000, ISO 9001:2008
- Condition：New
- Drill Hole Diameter：>300mm
- Drill Hole Depth：>150m
Base Info
- Model NO.：SR400R-W10
- Bit Type：Cone Bit
- Drilling Way：Compound
- Type：Crawler
- Rated Power：377,1800kw,Rpm
- Lifting Capacity：400kn
- Max. Line Speed：60m,Min
- Operating Weight：162t
- Overall Height：30730mm
- Transport Height：3810mm
- Transport Width：3600mm
- Transport Package：Container
- Trademark：cruking
- Origin：China
- Production Capacity：100sets,Month
Description
Model
SR235-W10
SR285R-W10
SR400R-W10
SR405R-W10
Max. Pile Diameter
2000/1500mm
2200/1900mm
2500/2200mm
2500/2200mm
Max. Pile Depth
68/54m
94/61m
106/88m
106/88m
Rated Output Torque
235kN·m
285kN·m
400kN·m
405kN·m
Rated Speed
5~27rpm
5~24rpm
5~22rpm
5~25rpm
Crowd Force
210kN
260kN
350kN
350kN
Line Pull
270kN
355kN
380kN
400kN
Stroke
15000mm
17100mm
9000/18000mm
13000mm
Lifting Capacity
270kN
355kN
410kN
400kN
Rope Diameter
20mm
20mm
36mm
36mm
Max. Line Speed
70m/min
70m/min
70m/min
75m/min
Base Engine
6UZ1
6WG1
6WG1
6WG1
Engine Power
257/2000kW/rpm
300/1800kW/rpm
300/1800kW/rpm
377/1800kW/rpm
Emission Regulation
Tier III
Tier III
Tier III
Tier III
Overall Height
22870mm
25410mm
27105mm
27700mm
Operating Weight
81T
105T
137T
131T
Transport Width
3540mm
3475mm
3500mm
3500mm
Transport Height
3575mm
3610mm
3575mm
3660mm
