Rotary Drilling Rig for Water Well, Geotechnical Investigation, Diamond Core Drilling (HGY-200)

Changsha Miracleland Import & Export Co., Ltd.
  • Condition：New
  • Motor：AC Motor
  • Drill Hole Diameter：>300mm
  • Drill Hole Depth：>200m
  • Bit Type：Diamond Bit
  • Drilling Way：Rotary

Base Info

  • Model NO.：HGY-200 Soil Testing Drilling Rig
  • Type：Core Drilling Rig
  • Drilling Depth：200m
  • Spindle Hole Diameter (mm)：63mm, 95mm
  • Spindle Output Torque (N.M)：1700
  • Weight(Power Unit Excepted) (Kg)：750
  • Usage：Coal, Ore, Water Well, Geotechnical Engineering
  • Power Type：Diesel
  • Transport Package：in Plywood Case
  • Specification：CE, ISO2008: 9001, SGS
  • Trademark：FLYDISC
  • Origin：Changsha, Hunan, China
  • HS Code：8430691900
  • Production Capacity：30 Sets,Month

Description

Basic Info.

Model NO. HGY-200 Soil Testing Drilling Rig Type Core Drilling Rig Drilling Depth 200m Spindle Hole Diameter (mm) 63mm, 95mm Spindle Output Torque (N.M) 1700 Weight(Power Unit Excepted) (Kg) 750 Usage Coal, Ore, Water Well, Geotechnical Engineering Power Type Diesel Transport Package in Plywood Case Specification CE, ISO2008: 9001, SGS Trademark FLYDISC Origin Changsha, Hunan, China HS Code 8430691900 Production Capacity 30 Sets/Month

Product Description

HGY-200 Portable Soil Testing Drilling Rig:

Drilling depth(m): 200;
LxWxH(mm): 1860X800X1400;
Spindle stroke(mm): 500;
Diesel engine: ZS1110(14.7 KW);
Electromotor: Y160L-4(15KW);

Product Features:

Good stability and high reliability.
Multilevel positive and reverse rotate speed.
The complete hydraulic chuck and vertical spindle.
Convenient to transport with the small volume and light weight.
Perfect frame's rigidity, low center of gravity and good stability.

Product Application:

It is widely used in the construction of the projects e. g. Prospecting, railway, road, port, bridge, water conservancy and hydropower, tunnel, well, industrial and civil construction, geological exploration, large diameter boring pile and small diameter diamond core deep hole drilling, etc.

Rotary Drilling Rig for Water Well, Geotechnical Investigation, Diamond Core Drilling (HGY-200)

Rotary Drilling Rig for Water Well, Geotechnical Investigation, Diamond Core Drilling (HGY-200)
Rotary Drilling Rig for Water Well, Geotechnical Investigation, Diamond Core Drilling (HGY-200)Rotary Drilling Rig for Water Well, Geotechnical Investigation, Diamond Core Drilling (HGY-200)
 Type HGY-200 Drilling Rig
 Drilling depth(m) 200
 Drilling rod diameter(mm) Φ50
 Head angle range 360°
 Cylinder stroke(mm) 360
 Spindle speed(r/min) Positive rotation rate:60150240340550830
 Reverse rotation rate:  3585135195330480
 Spindle hole diameter(mm) Φ65 Φ95
 Spindle output torque(N.M) 2140
 Spindle stroke(mm) 500
 Spindle driving force max.(KN) 37
 Spindle lifting power max.(KN) 50
 Lifting speed(m/s) 0.62.33.4
 Single rope lifting powder(KN) 20
 Steel wire rope diameter(mm) Φ11
 Mode of chuck Full hydraulic chuck or ball-type chuck
 Weight(power unit excepted)(kg) 750
 LxWxH(mm) 1860x800x1400
 Dieselengine ZS1110(14.7KW)
 Electromotor Y160L-4(15KW)
