• Model NO.：KDX-4
• Power：132kw
• Rated Rpm(Factory Setting)：2200rpm
• Max. Torque：4200 N·m
• Hold Diameter：98mm
• Max. Lifting Capacity of Spindle：150 Kn
• Max. Feeding Power：60 Kn
• Hoisting Force (Single Wire)：57kn
• Mud Pump：Bw150
• Weight：9300kg
• Transport Package：Nude
• Specification：4200n. m
• Trademark：kudat
• Origin：China

Diesel EngineModelCummins 6BTA5.9-C180Power132kWRated RPM(Factory setting)2200rpmDrilling CapacityBQ1000 mNQ700 mHQ500 m Power head ability
 RPMFour Shifts/ Stepless Change 0-1100 RPMMax. Torque4200 N·m
 Hold DiameterΦ98mmMax. Lifting capacity of Spindle150 kNMax. Feeding Power60 kNCapacity of Main HoistHoisting force (single wire)57kNSteel Wire Diameter12 mmSteel Wire Length50 mCapacity of Wire line HoistHoisting force (single wire)12kNSteel Wire Diameter6 mmSteel Wire Length1000 mMastMast Height11 mMast Adjusting Angle0°-90°Drilling Angle45º off horizontal to 90ºvertical down
 Feeding Stroke3500 mmSlippage Stroke600 mmOtherWeight9300 KgTransport Dimensions (L × W ×H )5100×2200×2890mm
(232.3×88.1×98.4 inch)Transport WaySteel CrawlerMud PumpModelBW150Foot ClampClamping Scope55.5-117.5 mm
through hole Ф154mm
