Kr125m Cfa Spiral Crawler Piling Rig for Max Piling Depth15m, Small Foundation Equipment
TYSIM Piling Equipment Co., Ltd.- Certification：CE, ISO 9001:2000
- Condition：New
- Drill Hole Diameter：>300mm
- Drill Hole Depth：10-30m
- Drilling Way：Rotary
- Type：Crawler
Base Info
- Model NO.：KR125M
- Torque：125 Kn.M
- Max. Diameter：700 mm
- Max. Drilling Depth：15 M
- Ocerall Weight：32 T
- Main Pull：110 Kn.M
- Transport Package：Bulk Pack
- Specification：32 t
- Trademark：tysim
- Origin：Jiangsu, China
- HS Code：8430412900
- Production Capacity：30pieces,Month
Description
CFA construction method Max. diameter 700mm Max. drilling depth 15m Main winch line pull 230 kN Rotary drilling construction method Max. Diameter 1500 mm Max. drilling depth 37 m Main winch line pull 120 kN Main winch line speed 78 m/min Working parameters Max. torque 125 kN.m Auxiliary winch line pull 60 kN Auxiliary winch line speed 60 m/min Mast inclination(lateral) ±3° Mast inclination(forward) 3° Max. operating pressure 34.3 MPa Pilot pressure 3.9 MPa Travel speed 2.8 km/h Traction force 204 kN Operating size Operating height 18200 mm(CFA)/14800mm(rotary drilling) Operating width 2990 mm Transport size Transport height 3500 mm Transport width 2990 mm Transport length 13960 mm Total weight Overall weight 35 t
FAQ
Q1: What is the Warranty of the Rotary Drilling Rig?
The warranty period for new machine is an year or 2000 working hours, whichever comes first will be applied.
Please contact with us for detailed Warranty Regulation.
Q2: What's your service ?
We can offer professional technical support and good after-sale service to you.
Modification methods will be different according to different models and configurations of your owned excavators.
Before modifying, you need to provide configuration, mechanical and hydraulic joints and others.
Before modifying, you need to confirm technical specification.
Product Details
1. Undercarriage-----Reliable & Mature Excavator Supplier for Choice
Type: New & Used
Brand: CAT, JCM, SINOMACH, SANY, XCMG and other
2. Hydraulic Parts-----Famous Brands
Gearbox Reducer: Imported REXROTH
Main Pump & Valve: Imported KAWASAKI (Japan)
Hose: Imported
3. Structure Parts-----Professional Structure Parts Supplier for XCMG
Why Choose Us?
1. We are the professional & trustworthy manufacturer of piling machinery in China, best quality & best service.
2. Supply professional customized service to meet all your requirements.
3. Our rotary drilling rigs have been sold to more than 7 counstries, such as Russia, Australia, Thailand, Zambia and others.
4. Competitive price.
FAQ
Q1: What is the Warranty of the Rotary Drilling Rig?
The warranty period for new machine is an year or 2000 working hours, whichever comes first will be applied.
Please contact with us for detailed Warranty Regulation.
Q2: What's your service ?
We can offer professional technical support and good after-sale service to you.
Modification methods will be different according to different models and configurations of your owned excavators.
Before modifying, you need to provide configuration, mechanical and hydraulic joints and others.
Before modifying, you need to confirm technical specification.
