140-350 mm Crawler Water Rig Bore Tube Truck Mounted Machine Deep Well Drilling
Quzhou Zhongdu Machinery Technology Co., Ltd.- Warranty：1 Year
- Certification：CE, ISO 9001:2000, ISO 9001:2008
- Condition：New
- Drill Hole Diameter：140-350 mm
- Drill Hole Depth：580m
- Bit Type：Diamond Bit
Base Info
- Model NO.：FY580
- Drilling Way：Compound
- Type：Crawler
- The Hole Diameter：140-350 mm
- Drill Pipe Diameter：102mm; 108mm; 114mm
- Drill Pipe Length：1.5m 2.0m 3.0m 6.0m
- Engine：Diesel
- Engine Brand：Cummins
- Rated Power：132 Kw
- Rig Lifting Force：28 T
- Rapid Rise Speed：20 M,Min
- Walking Speed：2.5 Km,H
- Climbing Angles (Max.)：30 Degrees
- Using Air Pressure：1.7-3.5 MPa
- Air Consumption：17-42 M3,Min
- Equipped with Hammer：Medium and High Wind Pressure Series
- Dimensions：6200*2200*2650 mm
- Weight：12 T
- Transport Package：Container
- Specification：6200*2200*2650 mm
- Origin：Zhejiang
- HS Code：8430419000
- Production Capacity：20PCS Per Month
Description
Overview
Product Description
Detailed Photos
Company Profile
FAQ
Q1: Are you factory or trade company?
A1: We are factory. And we have ourselves trading company.
Q2: What the exactly address of your factory?
A2: Our company is located in Kaixuan Road ,Economic Zone Quzhou, Zhejiang, China
Q3: Warranty terms of your machine?
A3: One year warranty for the machine and technical support according to your needs.
Q4: Will you provide some spare parts of the machines?
A4: Yes, of course.
Q5: What about the voltage of products? Can they be customized?
A5: Yes, of course. The voltage can be customized according to your equirement.
Q6: Which payment term can you accept?
A6: 30% T/T in advanced, 70% T/T against the B/L copy.
