JK-DR400 400m Water Well Drilling Rig for Sale
Shandong JK Machinery Co., Ltd.- Certification：CE, ISO 9001:2008
- Condition：New
- Motor：DC Motor
- Drill Hole Diameter：140-350mm
- Drill Hole Depth：400m
- Bit Type：Diamond Bit
Base Info
- Model NO.：JK-DR400
- Drilling Way：Rotary
- Type：Crawler
- Usage：Water Well
- Voltage：24V
- Weight：10T
- Warranty：1 Year
- Power Type：Diesel
- Product Name：Water Well Drilling Rig
- Transport Package：40HC
- Specification：5900*2100*2850mm
- Trademark：SDJK
- Origin：Shandong
- HS Code：8430412100
- Production Capacity：100sets,Month
Description
The Main Parameters Model JK-DR400 Weight 10T Bore diameter 140-350mm Drilling depth 400m Stroke 6.6m Travelling speed 2.5km/h Gradeability 30% Power 92KW Rated pressure 1.7-3.5mpa Air consumption 17-35m³/min Drill rod diameter Φ89, Φ102, Φ108 Drill rod length 1.5m 2.0m 3.0m 6.0m Elevating capacity 22T Swing speed 45-115rpm Swing torque 6500-9000N.M Dimensions 5900*2100*2850mm
