• Model NO.：ZT
• Drilling Way：Impactor
• Type：Crawler
• Working Air Pressure：1.05-3.45MPa
• Drilling Diameter：100-500mm
• Max. Rotation Torque：6500-8500nm
• Package：Standard Export Packing
• Axle Pressure：4t
• Walking Speed：3.5km,H
• Transport Package：Wood Box
• Specification：3.5T
• Trademark：ZT
• Origin：China
• Production Capacity：100sets,Mouth

Basic Info.

Model NO. ZT Drilling Way Impactor Type Crawler Working Air Pressure 1.05-3.45MPa Drilling Diameter 100-500mm Max. Rotation Torque 6500-8500nm Package Standard Export Packing Axle Pressure 4t Walking Speed 3.5km/H Transport Package Wood Box Specification 3.5T Trademark ZT Origin China Production Capacity 100sets/Mouth

Product Description

Hydraulic Crawler Drill Machine Water Well Drill Rig Rock Machine

Description:
1.low-speed high-torque hydraulic motor drive rotary device output torque required for drilling operations.
2.with the cylinder to promote, so that more stable propulsion, failure rate than the motor propulsion significantly reduced.
3.two-stage filter device to effectively ensure the safety of diesel engines to extend the life of diesel engines.
4.can monitor the hydraulic system pressure and push the pressure at any time to ensure that the rig stable and efficient operation.
Thoughtful service to win the trust of customers.

Hydraulic DTH Drill is a high-grade rig with a stent-type down-hole drilling rig with excellent performance and powerful features. Hydraulic downhole drilling rig, walking downhole drilling rig, open pit drill.

pneumatic crawler drill is mainly used for open-pit mine mining, hydropower engineering, road construction and other stone works crawler drilling machine operations.

Parameters:

Models	ZT100A
Drilling diameter	F=6~20
Drilling diameter	80~130mm
Drilling vertical hole depth	30m
monitor rate	20kw
Walking speed	2.0km/h
Single climbing ability	30°
Maximum lifting force	15KN
One push trip	3000mm
Working pressure	0.5-1.4Mpa
Gas consumption	7-12m³/min
Rotational speed	0-70r/min

Shaanxi Zhongtuo Mining Equipment Co., Ltd. is a global supplier who specializing in bridge stretching
equipment, downhole drill series, steel processing machinery, rock splitting equipment, grouting equipment
and pavement processing equipment. After years of hard work and development. We have established a
solid foundation for providing quality services with many years of experience in mechanical equipment
manufacturing. Our high-quality bridge equipment and mining machinery products such as bridge
stretching equipment, downhole drill series, steel processing machinery, rock splitting equipment,
grouting equipment and pavement processing equipment have been well received by users. In recent years
we have begun to focus on the development of international markets. ?With the continuous improvement of
high-quality products and high-quality services, our products are highly appreciated by customers in the
international market. Due to the excellent performance of the products and professional after-sales service
, our products have been sold to: Romania, Bulgaria, Albania, Colombia, Brazil, Peru, Uruguay, Saudi Arabia,
Kuwait, United Arab Emirates, Oman, Turkey, Israel, Kazakhstan, Sudan, Madagascar, etc. We have been
focusing on high-quality mechanical equipment and construction products for more than 20 years, and are
widely used in mining, construction and water conservancy projects, railway

FAQ:

Q1: Are you factory or trade company?
A1: We are factory. And we have ourselves trading company.

Q2: What the exactly address of your factory?
A2:  No.27, Beichen Village Industrial Park, Weiyang District, Shaanxi Province China.

Q3: Warranty terms of your machine?
A3: One year warranty for the machine and technical support according to your needs.

Q4: Will you provide some spare parts of the machines?
A4: Yes, of course.

Q5: What about the voltage of products? Can they be customized?
A5: Our standard voltage is 380V, 50HZ, 3phase. The voltage can be customized according to your equipment.

Q6: Which payment term can you accept?
A6: 100% T/T( Decide according to actual situation)

Q7: How long will you take to arrange production?
A7: we can delivery the normal goods within 7-15 days. Other nonstandard electrical items we will delivery within 25-30 days.

Q8: Can you accept OEM orders?
A8: Yes, with professional design team, OEM orders are highly welcome.

Q9: Which trade term can you accept?
A9: Available trade terms: FOB, CIF, CFR, EXW, etc.

Q10: Do you provide samples? Is it free or extra?
A10: Yes, we could offer you the sample machine. But it's not free. You need to pay for the sample and the cost of freight.

Q11: What is your terms of payment?
A11: We accept T/T, Western Union, Money Gram, Paypal, L/C, etc.
