• Model NO.：GL300 Core Drill Rig
• Drilling Way：Rotary
• Item：Gl300 Drill Rig
• Drilling Depth：300,250,150,100,80,M
• Drill Rod Dia.：50mm
• Initial Hole Dia.：75,91,110,13,150mm
• Angle Range：75-90
• Dimensions：1700*1030*1270 (mm)
• Final Hole Dia.：75mm
• Spindle Stroke：450mm
• Spindle Lifting Capacity Max：45 Kn
• Weight：750kg
• Usage：Core
• Power Type：Diesel
• Type：Core Drilling Rig
• Transport Package：Standard Export Packing
• Specification：ISO9001
• Trademark：GLORYTEK
• Origin：China
• Production Capacity：100000

Basic Info.

Model NO. GL300 Core Drill Rig Drilling Way Rotary Item Gl300 Drill Rig Drilling Depth 300/250/150/100/80/M Drill Rod Dia. 50mm Initial Hole Dia. 75/91/110/13/150mm Angle Range 75-90 Dimensions 1700*1030*1270 (mm) Final Hole Dia. 75mm Spindle Stroke 450mm Spindle Lifting Capacity Max 45 Kn Weight 750kg Usage Core Power Type Diesel Type Core Drilling Rig Transport Package Standard Export Packing Specification ISO9001 Trademark GLORYTEK Origin China Production Capacity 100000

Product Description

GL300 DRILL RIG
Specifications
drilling machine
1.multi-functions
2.easy to operate
3.high quality
4.reasonable price


core  drilling machine
GL-300 Drilling machine is a new type of vertical spindle machine manufactured by Jing Di, for which a diesel engine or motor may be chosen as power. It is primarily used with diamond drill bit or carbide drill bit for the drilling in solid mineral deposit as well as those in engineering geotectonic survey, foundation pile hole and water well hole.
1. Compact mechanical transmission structure, lightweight, vertical spindle for large through hole diameter with hexagonal drive drilling rod, ensured torque transmission.
2. Higher rotating speed and rational scope, adaptable for the drillings with small diameter diamond drill bit or large diameter carbide drill bit and other engineering hole drillings.
3. During the hydraulic controlled feeding process, both the pressure and speed of feeding can be regulated to meet the requirements of different stratum drillings.
4. Less and centralized handles, easy operation.

Technical Specifications

  Drill
Drill rod dia.                                          50mm
 Drilling depth                                      300/250/150/100/80/m
 Initial hole dia.                                       75/91/110/13/150mm
 Final hole dia.                                        75mm
 Angle range                                          75°-90°
Dimensions(L×W×H)                       1700×1030×1270 (mm)
Weight(without power unit)                    750kg

 Swivel Head
Spindle speed
 Forward                                     85/125/230/375/560/1000 r/min
 Reverse                                              69 r/min
 Spindle stroke                                      450mm
 Spindle lifting capacity max                   45 KN
 Spindle pull-down max                          39KN
 Spindle max.torque                              1.7KN.m
 Spindle upward moving max            2.4,4.8m/min

 Hoist
Reel speed                                22/34/62/100/150/270 r/min
Reel diameter                             145mm
Hoisting drum linear velocity                 0.18/0.30/0.54/0.86/1.3/2.3m/s
Max .lifting capacity (single rope)            20KN
Wire rope dia                                          9.3mm
Wire rope capacity                        35m
Drum dia.                                             252mm
Gate width                                50mm

 Oil Pump
Type                                    Gear pump
 Model                                                YBC-30/80
 Rated displacement                             20ML/r
 Rated pressure                                     8Mpa
Rated speed                             1500r/min


Power (diesel engine or motor)
 Model (diesel engine)                           L28N
Rated power                                         20KW
 Rated speed                                      2000r/min
 Model (motor)                                     Y160L-4
 Rated power                                        15KW
Rated speed                                       1440r/min
