• Model NO.：ZT-25
• Drilling Angle：0-90(° )
• Rotator Travel：3400(mm)
• Walking Way：Crawler Walking
• Weight：6000(Kg)
• Transport Package：Wooden Box
• Trademark：ZT
• Origin：China
• Production Capacity：1000sets,Mouth

Basic Info.

Model NO. ZT-25 Drilling Angle 0-90(° ) Rotator Travel 3400(mm) Walking Way Crawler Walking Weight 6000(Kg) Transport Package Wooden Box Trademark ZT Origin China Production Capacity 1000sets/Mouth

Product Description

Introduction of Crawler Type Borehole Hydraulic Water Well Drilling Rig Rock Drill:
1.full hydraulic control, instrument display, shaving convenient and flexible, greatly improving the efficiency and meet the needs of customers.
2.gripper can be broken from the lake bolt and casing, reducing the labor intensity of workers, poles demolition efficiency.
3.Clamping cylinder The plug is adjustable to use the Φ 60mm anchor, front and rear grippers.
The customer's request is our work standard

Crawler Type Borehole Hydraulic Water Well Drilling Rig Rock Drill Description:
The Crawler Mounted Anchor Drilling Rig is integrated, with tracked walking chassis and clamping shackle. Crawler chassis moving quickly, the hole is convenient; clamping shackle can automatically remove the drill pipe and casing, reducing the labor intensity of workers to improve the construction efficiency.

Crawler Type Borehole Hydraulic Water Well Drilling Rig Rock Drill Use:
The model belongs to the crawler mounted anchor drilling, which is mainly applied to the construction of the foundation pit support and the control of the building displacement and the geological disaster control.

Crawler Type Borehole Hydraulic Water Well Drilling Rig Rock Drill Parameters:

Drilling diameter	ф150-ф250(mm)
Drilling depth	130-170(m)
Final hole diameter	75mm
Drill pipe diameter / casing diameter	Ф73,ф89,ф102,ф114(mm)
Drilling angle	0-90(° )
Rotator output speed	10/20/30/35/40/60/65/70/85/130/170(r/min)
Rotator Output Torque	7500(N.m)
Rotator travel	3400(mm)
Rotator lift force	70(kN)
Rotator lift speed	0-5 adjustable /7/23/30(m/min)
Rotor pressure	36(kN)
Rotary press speed 0-10 adjustable	0-10 adjustable /14/46/59(m/min)
Walking way	crawler walking
Climbing angle	25(° )
Crawler ground pressure	36(kpa)
Walking speed	20(km/h)
Rotary mode	the whole machine manual rotation (automatic rotation optional)
Rotary structure	slewing bearing
Positioning	Positioning Pins
Input power (motor)	55+18.5(KW)
Shipping status (degrees x width x height)	5400x2100x2000(mm)
Weight	6000(kg)

10 good reasons why you should buy from us?
1.we are a real factory offering products
2.free technical advice by QUALIFIED MECHANICAL ENGINEER
3.company in business for many years
4.over 50 countries customers served!
5.buy direct saving your money!
6.all machine with CE, ISO,SGS certificate.
7.machine and spindle warranty 1 year.
8.our engineer can go to your country to provide technical guidance
9.we have phone support in English, if you have any questions, you can call it,
    we can give you a best solution within 24 hours
10.fast delivery, save your time.



Welcome to your inquiry,we can customize for your every inquiry,thanks
