300m Truck Mounted Full Hydraulic Top Drive Water Well Drilling Rig (FY-300)
Changsha Miracleland Import & Export Co., Ltd.- Certification：CE, ISO 9001:2008
- Condition：New
- Motor：Diesel Engine
- Drill Hole Diameter：146-325mm
- Drill Hole Depth：300m
- Bit Type：DTH Bit
Base Info
- Model NO.：FY300
- Drilling Way：DTH Hammer
- Type：Truck Mounted
- Usage：Water Well
- Truck Brand：Dongfeng
- Quality：High Quality
- Transport Package：Plastic Film
- Specification：300
- Trademark：FY
- Origin：China
- HS Code：8430412900
- Production Capacity：20 Sets,Month
Description
FY-300 truck mounted full hydraulic DTH water well drilling rig technical figuresDrilling depth 300m Drilling diameter Φ146-Φ325mm Working air pressure 1.7-3.3MPa Air consumption 17-35m3/min Drilling pipe diameter Φ89,Φ102 Rig length of drill pipe 1.5m,2.0m,3.0m Rig one push length 6.6m Truck tramming speed 85km/h Truck brand Dongfeng 170 Truck chassis 4x2 Fuel type Diesel oil Truck power 118kw Truck flow 6234 ml Truck Fuel consumption per 100km 16.2 L Rig rotation speed 55-115 rpm Rig rotation torque 7200-9500 N.m Rig power 85 KW Weight 23T Transportation dimension 9000x2470x3450mm Mud pump model BW-250 Pump flow 250 L/min Pump diesel engine model ZS1115 (15kw))
