• Model NO.：ZP495
• Drilling Way：Compound
• Max.Speed：300r,Min
• Inner Diameter：1257.3mm
• Gear Ratio：3.93
• Hardness：HRC58-62
• Certificate：ISO,API
• Material：Steel
• Process：Hobbing
• OEM：Ok
• Others：Customized in Drawing or Samples
• Shape：Helical Gear
• Transport Package：Polywood Case
• Specification：ISO, API
• Trademark：Baoxin
• Origin：Changzhou, Jiangsu, China
• HS Code：848340900
• Production Capacity：300PCS,Year

Overview

Product Description

ModelZP175ZP205ZP275ZP375ZP375ASZP495ZP205ADiameter of openingmm444.5520.7698.5952.5952.51257.3520        (in)17.520.527.537.537.549.520.5

Distance from table axis to center inner row of sprocket teeth

mm1,1181,3531,3531,3531,4781,6511,353        (in)4453.2553.2553.2558.186553.25Max.static load ratingkN1,3503,1504,5005,8505,8507,2502,000        lbs300,000700,0001,000,0001,300,0001,300,0001,600,000440,000Max.working torqueNm13,72922,55527,45932,36232,36236,28513,729        lb.ft10,13216,64620,26523,88323,88326,77810,132Max.speedr/min300300300300300300300Gear ratio3.583.223.673.563.563.933.22

Overall dimensions

(LxWxH)

mm

1,935x200

x585

2,291.5

x1,475

x668

2,392x

1,670x

685

2,468x

1,810x

718

2,468x

1,810x

718

2,940x

2,184x

813

2,250x

1,440x

659

        (in)76x11x2390x58x2694x65x2797x71x2891x71x28116x86x3289x57x26Weightkg3,8885,5306,1637,5488,02611,6264,560        lbs8,60012,00013,58716,60017,70025,60010,000

Detailed Photos

Gear Features

Company Profile

Certifications

Packaging & Shipping

Customer Visiting

ISO9001:2008 Quality Certification:

Our Service:

If you are interested in any of our products, please contact me freely! Warmly Welcomed your visit to our factory in China, OEM service will be ok.
