180kn Small Horizontal Directional Drilling Rig HDD Machine Xz180 for Sale Made in China

Newindu Construction Engineering (Shanghai) Co., Ltd.
  • After-sales Service：Online Support
  • Warranty：1 Year
  • Certification：CE, RoHS, ISO 9001:2000, ISO 9001:2008
  • Condition：New
  • Drill Hole Diameter：<100mm
  • Drill Hole Depth：10-30m

Base Info

  • Model NO.：XZ180
  • Bit Type：Cone Bit
  • Drilling Way：Rotary
  • Type：Crawler
  • Max.Pullback/Thrusting：180kn
  • Rated Power：97kw
  • Overall Weight：8500kg
  • Backreaming Diameter：600mm
  • Color：Yellow
  • Engine：Cummins,Weichai,Yanmar
  • Transport Package：Nude Package
  • Specification：6400*2270*2340mm
  • Trademark：Chinese Brand
  • Origin：Jiangsu, China
  • HS Code：84305090
  • Production Capacity：50units,Month

Description

ModelXZ180EngineCUMMINSRated power97kWPush-pullMotorMax.pullback/thrusting180/180kNSpindle torque(max)6000N.mSpindle speed0~140r/minTravelling speed of power head20m/minBackreaming diameter600mmPipe length(single)3mPipe diameterΦ60mmEntry angle10-22°Mud flow ratw(max)250L/minMud pressure(max)80barOverall weight8500kgDimension(LxWxH)6400x2270x2340mm
