Top Brand 1200m Water Well Drilling Rig in Stock
Evangel Industrial (Shanghai) Co., Ltd.- After-sales Service：1 Year
- Warranty：1 Year
- Certification：CE, ISO 9001:2000
- Condition：New
- Motor：AC Motor
- Drill Hole Diameter：>300mm
Base Info
- Model NO.：XSC30,1200
- Drill Hole Depth：>200m
- Bit Type：Cone Bit
- Drilling Way：Rotary
- Type：Crawler
- Max. Crowd Force：260kn
- Max. Passing Diameter：820mm
- Transport Package：RO-RO
- Specification：14200*2550*4000mm
- Trademark：Top brand
- Origin：China
- Production Capacity：10set, Year
Description
SN
Item
Unit
Parameter value
1
Max extraction force
kN
1200
2
Max. crowd force
kN
260
3
Engine of upper part
Model
/
C18
4
Rated power/ speed
kW
571/2100
5
Jacking-driven power head
Torque/ rotation speed
kN.m / r/min
27.5 / 0~120
6
18.3 / 0~180
7
High lifting speed
m/min
30
8
High lowering speed
m/min
60
9
Stroke
mm
15200
10
Diameter of center shaft
mm
105
11
Working platform
Max. passing diameter
mm
Φ820
12
Tool winch
Extraction force
kN
50
13
Shackle device
Shackle Torque
kN.m
85
14
Air mud pipeline
Max. bearing pressure
MPa
35
15
Passing diameter
mm
76
16
Dedicated chassis
Driving form
/
10×8
17
Rated Power/ speed
kW
327/1900
18
Max. travel speed
km/h
80
19
Min. swerving diameter
m
24
20
Working dimension
Length×width×height
mm
14680×5184×(13800~21400)
21
Transportation dimension
Length×width×height
mm
14200×2550×4000
22
Overall weight
/
kg
55000
